Test Setup - Test Configurator, Timer, and System
Power Blazer 169
RFC 2544 - Global
Frame Distribution

Frame Distribution allows to select either RFC 2544 (default) or User
Defined distribution.

Quantity is only available when User Defined is selected and allows to
select the number of frames, from 1 to 7 (default), in the distribution.

Frame Size (Bytes): For RFC 2544 distribution, gives predefined frame
size distribution values. For User Defined distribution, enter up to
seven frame size values.
The following table lists each component that may affect the minimum
size value.
Restore RFC 2544 Defaults
Reverts the configured parameters to their default values.
Distribution Frame Size
RFC 2544 64 a ,128, 256, 512, 1024, 1280, and 1518
a. The minimum frame size will be adjusted according to the frame structure and
components selected.
User Defined 64 a to 16000 b
b. The maximum frame size is limited to 10000 for 10/100/1000Mbps electrical
interface.
Component Description
VLAN 4 bytes per VLAN tag (up to 3 VLAN tags)
LLC and SNAP Headers 8 bytes
IPv4 20 bytes
IPv6 40 bytes
