2-16 DGC-2020 Human-Machine Interface 9400200990 Rev K
o REGUL OFFSET
o CLOSING ANGLE
o VG>VB
o TIME DELAY
o FAIL DELAY
BIAS CONTROL
 AVR BIAS CONTROL
o CONTACT (Visible when LSM-2020 is disabled or when LSM-2020 is enabled and OUTPUT TYPE =
CONTACT.)
 TYPE

CORRECTION PULSE (Visible when OUTPUT TYPE = CONTACT and CONTACT TYPE =
PROPORTIONAL.)
 WIDTH
 INTERVAL
o VAR CTRL
 DROOP
 DROOP
GAIN
 VAR CTRL ENABLE (Visible when LSM-2020 is enabled.)
 VAR CTRL MODE (Visible when LSM-2020 is enabled.)
 KP (Visible when LSM-2020 is enabled.)
 RAMP RATE (Visible when LSM-2020 is enabled.)
 kVar SETPT (Visible when LSM-2020 is enabled.)
 kVar SRC (Visible when LSM-2020 is enabled.)
 kVar ALG MAX (Visible when LSM-2020 is enabled.)
 kVar ALG MIN (Visible when LSM-2020 is enabled.)
 PF SETPT (Visible when LSM-2020 is enabled.)
 PF SRC (Visible when LSM-2020 is enabled.)
 PF ALG MAX (Visible when LSM-2020 is enabled.)
 PF ALG MIN (Visible when LSM-2020 is enabled.)
 KI (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 KD (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 TD (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 LOOP GAIN (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
o OUTPUT (Visible when LSM-2020 is enabled.)
 TYPE
o VOLT CTRL GAINS (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 KP
 KI
 KD
 TD
 LOOP
GAIN
 GOV BIAS CONTROL
o CONTACT (Visible when LSM-2020 is disabled or when LSM-2020 is enabled and OUTPUT TYPE =
CONTACT.)
 TYPE
o SPEED TRIM
 ENABLE
 KP

KI (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 KD (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 TD (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 LOOP GAIN (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 SETPOINT
o KW CTRL
 LOAD CTRL ENABLE (Visible when LSM-2020 is enabled.)
 KP (Visible when LSM-2020 is enabled.)
 KI (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 KD (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 TD (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 LOOP GAIN (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
 DROOP
 DROOP
GAIN
 RAMP RATE (Visible when LSM-2020 is enabled.)
 BASELOAD LVL (Visible when LSM-2020 is enabled.)
 BL LV SRC (Visible when LSM-2020 is enabled.)
 PF SRC (Visible when LSM-2020 is enabled.)
