B-42 DGC-2020 Modbus
 Communication
9400200990 Rev K
Register Description Type Units
Scaling
Factor
R/W Range
45504 Analog Input 3 Metering
Value Int32 DeciUnit Deci R (-99990) - 99990
45506 Analog Input 4 Metering
Value Int32 DeciUnit Deci R (-99990) - 99990
45508 Analog Input 5 Metering
Value Int32 DeciUnit Deci R (-99990) - 99990
45510 Analog Input 6 Metering
Value Int32 DeciUnit Deci R (-99990) - 99990
45512 Analog Input 7 Metering
Value Int32 DeciUnit Deci R (-99990) - 99990
45514 Analog Input 8 Metering
Value Int32 DeciUnit Deci R (-99990) - 99990
45516 RTD Input 1 Metering
Value Int32 CentiDeg F Centi R (-9999999) - 9999999
45518 RTD Input 2 Metering
Value Int32 CentiDeg F Centi R (-9999999) - 9999999
45520 RTD Input 3 Metering
Value Int32 CentiDeg F Centi R (-9999999) - 9999999
45522 RTD Input 4 Metering
Value Int32 CentiDeg F Centi R (-9999999) - 9999999
45524 RTD Input 5 Metering
Value Int32 CentiDeg F Centi R (-9999999) - 9999999
45526 RTD Input 6 Metering
Value Int32 CentiDeg F Centi R (-9999999) - 9999999
45528 RTD Input 7 Metering
Value Int32 CentiDeg F Centi R (-9999999) - 9999999
45530 RTD Input 8 Metering
Value Int32 CentiDeg F Centi R (-9999999) - 9999999
45532 Thermocouple Input 1
Metering Value Int32 CentiDeg F Centi R (-9999999) - 9999999
45534 Thermocouple Input 2
Metering Value Int32 CentiDeg F Centi R (-9999999) - 9999999
45536 AEM Input Threshold
Status Bits Reg 1 Uint32 N/A N/A R Bit 0 = Analog Input 1 Out of Range
Bit 1 = Analog Input 1 Over 1
Bit 2 = Analog Input 1 Over 2
Bit 3 = Analog Input 1 Under 1
Bit 4 = Analog Input 1 Under 2
Bit 5 = Analog Input 2 Out of Range
Bit 6 = Analog Input 2 Over 1
Bit 7 = Analog Input 2 Over 2
Bit 8 = Analog Input 2 Under 1
Bit 9 = Analog Input 2 Under 2
Bit 10 = Analog Input 3 Out of Range
Bit 11 = Analog Input 3 Over 1
Bit 12 = Analog Input 3 Over 2
Bit 13 = Analog Input 3 Under 1
Bit 14 = Analog Input 3 Under 2
Bit 15 = Analog Input 4 Out of Range
Bit 16 = Analog Input 4 Over 1
Bit 17 = Analog Input 4 Over 2
Bit 18 = Analog Input 4 Under 1
Bit 19 = Analog Input 4 Under 2
Bit 20 = Analog Input 5 Out of Range
Bit 21 = Analog Input 5 Over 1
Bit 22 = Analog Input 5 Over 2
Bit 23 = Analog Input 5 Under 1
Bit 24 = Analog Input 5 Under 2
Bit 25 = Analog Input 6 Out of Range
Bit 26 = Analog Input 6 Over 1
Bit 27 = Analog Input 6 Over 2
Bit 28 = Analog Input 6 Under 1
Bit 29 = Analog Input 6 Under 2
