B-40 DGC-2020 Modbus
 Communication
9400200990 Rev K
Register Description Type Units
Scaling
Factor
R/W Range
44956 Local Configurable Inputs
Alarm Bits Int32 N/A N/A R Bit 0 = Input 1
Bit 1 = Input 2
Bit 2 = Input 3
Bit 3 = Input 4
Bit 4 = Input 5
Bit 5 = Input 6
Bit 6 = Input 7
Bit 7 = Input 8
Bit 8 = Input 9
Bit 9 = Input 10
Bit 10 = Input 11
Bit 11 = Input 12
Bit 12 = Input 13
Bit 13 = Input 14
Bit 14 = Input 15
Bit 15 = Input 16
44958 Configurable Elements
Status Bits Int32 N/A N/A R Bit 0 = Config Element 1
Bit 1 = Config Element 2
Bit 2 = Config Element 3
Bit 3 = Config Element 4
Bit 4 = Config Element 5
Bit 5 = Config Element 6
Bit 6 = Config Element 7
Bit 7 = Config Element 8
44960 Configurable Elements
Pre-Alarm Bits Int32 N/A N/A R Bit 0 = Config Element 1
Bit 1 = Config Element 2
Bit 2 = Config Element 3
Bit 3 = Config Element 4
Bit 4 = Config Element 5
Bit 5 = Config Element 6
Bit 6 = Config Element 7
Bit 7 = Config Element 8
44962 Configurable Elements
Alarm Bits Int32 N/A N/A R Bit 0 = Config Element 1
Bit 1 = Config Element 2
Bit 2 = Config Element 3
Bit 3 = Config Element 4
Bit 4 = Config Element 5
Bit 5 = Config Element 6
Bit 6 = Config Element 7
Bit 7 = Config Element 8
44964 Remote Inputs Status Bits Int32 N/A N/A R Bit 0 = Remote Input 17
Bit 1 = Remote Input 18
Bit 2 = Remote Input 19
Bit 3 = Remote Input 20
Bit 4 = Remote Input 21
Bit 5 = Remote Input 22
Bit 6 = Remote Input 23
Bit 7 = Remote Input 24
Bit 8 = Remote Input 25
Bit 9 = Remote Input 26
