9400200990 Rev K DGC-2020 Modbus
 Communication
B-31
Register Description Type Units
Scaling
Factor
R/W Range
44306 Underfrequency Alarm
Configuration Uint32 N/A N/A RW 0 = None
1 = Alarm
2 = Pre-Alarm
44308 Overfrequency Pickup Uint32 DeciHertz Deci RW 450 - 4400
44310 Overfrequency Activation Delay Uint32 Decisecond Deci RW 0 - 300
44312 Overfrequency Alarm
Configuration Uint32 N/A N/A RW 0 = None
1 = Alarm
2 = Pre-Alarm
44314 Overcurrent Low Line Scale
Factor (51-1) Float N/A N/A RW 0 - 3
44316 Overvoltage Low Line Scale
Factor (59-1) Float N/A N/A RW 0 - 3
44318 Undervoltage Low Line Scale
Factor (27-1) Float N/A N/A RW 0 - 3
44320 3 Phase Overcurrent Pickup (51-
2) Uint32 CentiAmp Centi RW 18 - 775
44322 3 Phase Overcurrent Time Dial
(51-2) Uint32 DeciUnit Deci RW 0 - 300
44324 3 Phase Overcurrent Curve (51-
2) Uint32 N/A N/A RW 0 = S1 Curve
1 = S2 Curve
2 = L1 Curve
3 = L2 Curve
4 = D Curve
5 = M Curve
6 = I1 Curve
7 = I2 Curve
8 = V1 Curve
9 = V2 Curve
10 = E1 Curve
11 = E2 Curve
12 = A Curve
13 = B Curve
14 = C Curve
15 = G Curve
16 = F Curve
44326 3 Phase Overcurrent Alarm
Configuration (51-2) Uint32 N/A N/A RW 0 = None
1 = Alarm
2 = Pre-Alarm
44328 1 Phase Overcurrent Pickup (51-
2) Uint32 CentiAmp Centi RW 18 - 775
44330 1 Phase Overcurrent Time Dial
(51-2) Uint32 DeciUnit Deci RW 0 - 300
44332 1 Phase Overcurrent Curve (51-
2) Uint32 N/A N/A RW 0 = S1 Curve
1 = S2 Curve
2 = L1 Curve
3 = L2 Curve
4 = D Curve
5 = M Curve
6 = I1 Curve
7 = I2 Curve
8 = V1 Curve
9 = V2 Curve
10 = E1 Curve
11 = E2 Curve
12 = A Curve
13 = B Curve
14 = C Curve
15 = G Curve
16 = F Curve
44334 1 Phase Overcurrent Alarm
Configuration (51-2) Uint32 N/A N/A RW 0 = None
1 = Alarm
2 = Pre-Alarm
44336 3 Phase Undervoltage Pickup
(27-2) Uint32 Volt N/A RW 70 - 576
