9400200990 Rev K DGC-2020 Human-Machine Interface 2-11
PROGRAMMABLE INPUTS
 CONFIGURABLE INPUTS
o INPUT X (X = 1 to 26)
 ALARM CONFIG
 ACTIVATN DLY
 RECOGNITION
 PROG FUNCTIONS
o AUTO XFER SWITCH
 INPUT

RECOGNITION (Visible when an INPUT is selected.)
o GRND DELTA O-RIDE
 INPUT

RECOGNITION (Visible when an INPUT is selected.)
o BATTLE OVERRIDE
 INPUT

RECOGNITION (Visible when an INPUT is selected.)
o LOW LINE OVERRIDE
 INPUT

RECOGNITION (Visible when an INPUT is selected.)
o 1 PHASE O-RIDE
 INPUT

RECOGNITION (Visible when an INPUT is selected.)
o 1 PHASE AC O-RIDE
 INPUT

RECOGNITION (Visible when an INPUT is selected.)
o BATT CHRG FAIL
 INPUT

RECOGNITION (Visible when an INPUT is selected.)
o LOW COOL LEVEL
 INPUT

RECOGNITION (Visible when an INPUT is selected.)
o FUEL LEAK DETECT
 INPUT

RECOGNITION (Visible when an INPUT is selected.)
 ANALOG INPUTS (Visible when AEM-2020 is enabled.)
o ALG_IN_X (X = 1 to 8)
 INPUT TYPE
 MIN VOLTAGE
 MAX VOLTAGE
 MIN CURRENT
 MAX CURRENT
 PARAM MIN
 PARAM MAX
 OVER 1
 THRESHOLD
 ALARM
CONFIG
 OVER 2
 THRESHOLD
 ALARM
CONFIG
 UNDER 1
 THRESHOLD
 ALARM
CONFIG
 UNDER 2
 THRESHOLD
 ALARM
CONFIG
 ARMING DELAY
 THR1 ACT DLY
 THR2 ACT DLY
 HYSTERESIS

OOR ALM CFG
 THERMAL INPUTS (Visible when AEM-2020 is enabled.)
o RTD_IN_X (X = 1 to 8)
 TYPE
 OVER
1
 THRESHOLD
 ALARM
CONFIG
