4-72 DGC-2020 BESTCOMSPlus Software 9400200990 Rev K
METERING EXPLORER
The Metering Explorer is a convenient tool within BESTCOMSPlus used to navigate through the following
metering screens of the DGC-2020 plug-in.
 Engine
 Generator
 Power
 Bias Control
 Run Statistics
 Status
 Inputs
o
Contact Inputs
o
Remote LSM Inputs
o
Remote Contact Inputs
o
Remote Analog Inputs
o
Remote RTD Inputs
o
Remote Thermocouple Inputs
o
Remote Analog Input Values
 Outputs
o
Contact Outputs
o
Configurable Elements
o
Remote Contact Outputs
o
Remote Analog Outputs
 Configurable Protection
 Alarms
 Event Log
 J1939 ECU
o
ECU Data
o
Engine Configuration
o
Active DTC
o
Previously Active DTC
 MTU
o
MTU Alarms
o
MTU Fault Codes
o
MTU Status
o
MTU Engine Status
 Summary
 Control
 Real Time Clock
 Generator Network Status
The Metering Explorer has a “Docking” feature allowing the user to arrange and dock metering screens. A
blue transparent square representing the screen being moved, seven arrow buttons, and a tabs button
appear when holding down the left mouse button on a metering tab and dragging it out. See Figure 4-66.
Table 4-2 explains the call-outs on Figure 4-66.
