9400200990 Rev K DGC-2020 Modbus
 Communication
B-51
Register Description Type Units
Scaling
Factor
R/W Range
46052 J1939-ADEC Cylinder
Cutout Code
Uint32 Raw ECU Parameter
Data
R No Scale or Offset
46054 J1939-ADEC Start
Sequence Bit Field
Uint32 Raw ECU Parameter
Data
R No Scale or Offset
46056 J1939-ADEC P Lube Oil
Limit LO Uint32 Raw ECU Parameter
Data
R 0.01 mbar per bit, 0 offset
46058 J1939-ADEC P Lube Oil
Limit LO LO Uint32 Raw ECU Parameter
Data
R 0.01 mbar per bit, 0 offset
46060 J1939-ADEC P Charge
Air Pressure
Uint32 Raw ECU Parameter
Data
R 0.01 mbar per bit, 0 offset
46062 J1939-ADEC AL Power
Amp 1 Fail Bit Fld
Uint32 Raw ECU Parameter
Data
R No Scale or Offset
46064 J1939-ADEC AL Power
Amp 1 Fail Bit Fld
Uint32 Raw ECU Parameter
Data
R No Scale or Offset
46066 J1939-ADEC AL
Transistor Out Bit Fl
Uint32 Raw ECU Parameter
Data
R
No Scale or Offset
46068 J1939-ADEC Camshaft
RPM
Uint32 Raw ECU Parameter
Data
R 0.1 rpm per bit, 0 offset
46070 J1939-ADEC Daily Fuel
Consumption
Uint32 Raw ECU Parameter
Data
R .0001 m³ per bit, 0 offset
46072 J1939-ADEC Frequency
Speed Demand.
Uint32 Raw ECU Parameter
Data
R .0001 m³ per bit, 0 offset
46074 J1939-ADEC Average
Trip Fuel Consumption
Uint32 Raw ECU Parameter
Data
R .001 l/h per bit, 0 offset
46076 J1939-ADEC Injection
Quantity DBR Pct
Uint32 Raw ECU Parameter
Data
R .01 % per bit, 0 offset
46078 J1939-ADEC Actual
Droop
Uint32 Raw ECU Parameter
Data
R .0001 % per bit, 0 offset
46080 J1939-ADEC Nodes On
CANbus Uint32 Raw ECU Parameter
Data
R No Scale or Offset
46082 J1939-ADEC Lost Nodes
on CANbus Uint32 Raw ECU Parameter
Data
R
No Scale or Offset
46084 J1939-ADEC Trip
Operating Time
Uint32 Raw ECU Parameter
Data
R 1 hour per bit, 0 offset
46086 J1939-ADEC Transistor
Out Bit Field
Uint32 Raw ECU Parameter
Data
R No Scale or Offset
46088 J1939-ADEC L1L ECU
Power Supply Volts Uint32 Raw ECU Parameter
Data
R .001 V per bit, 0 offset
46090 J1939-ADEC L2L ECU
Power Supply Volts Uint32 Raw ECU Parameter
Data
R 001 V per bit, 0 offset
46092 J939-ADEC U1LECU
Power Supply Volts
Uint32 Raw ECU Parameter
Data
R 001 V per bit, 0 offset
46094 J1939-ADEC U2L ECU
Power Supply Volts Uint32 Raw ECU Parameter
Data
R 001 V per bit, 0 offset
46096 J1939-ADEC Trip Idle
Time
Uint32 Raw ECU Parameter
Data
R 1 second per bit, 0 offset
46098 J1939-ADEC T Coolant
Limit Hi Uint32 Raw ECU Parameter
Data
R .01 Degree C per bit, 0 offset
46100 J1939-ADEC T Coolant
Limit Hi Hi Uint32 Raw ECU Parameter
Data
R 01 Degree C per bit, 0 offset
46102 J1939-ADEC T Charge
Air Limit Hi Uint32 Raw ECU Parameter
Data
R 01 Degree C per bit, 0 offset
