9400200990 Rev K DGC-2020 Modbus
 Communication
B-25
Register Description Type Units Scaling Factor R/W Range
42768 Gen Sensing Stable Overfrequency Pickup Int32 CentiHertz Centi RW 4600 - 6400
42770 Gen Sensing Stable Overfrequency Dropout Int32 CentiHertz Centi RW 4600 - 6400
42772 Gen Sensing Fail Time Delay Int32 Decisecond Deci RW 1 - 6000
42774 Gen Sensing Stable Time Delay Int32 Decisecond Deci RW 1 - 6000
42776 RESERVED
42778 Bus Sensing Dead Bus Pickup Int32 Volt N/A RW 1 - 4800
42780 Bus Sensing Dead Bus Time Delay Int32 Decisecond Deci RW 1 - 6000
42782 RESERVED
42784 Bus Sensing Stable Undervoltage Pickup Int32 Volt N/A RW 10 - 9999
42786 Bus Sensing Stable Undervoltage Dropout Int32 Volt N/A RW 10 - 9999
42788 Bus Sensing Stable Overvoltage Pickup Int32 Volt N/A RW 10 - 9999
42790 Bus Sensing Stable Overvoltage Dropout Int32 Volt N/A RW 10 - 9999
42792 Bus Sensing Stable Underfrequency Pickup Int32 CentiHertz Centi RW 4600 - 6400
42794 Bus Sensing Stable Underfrequency Dropout Int32 CentiHertz Centi RW 4600 - 6400
42796 Bus Sensing Stable Overfrequency Pickup Int32 CentiHertz Centi RW 4600 - 6400
42798 Bus Sensing Stable Overfrequency Dropout Int32 CentiHertz Centi RW 4600 - 6400
42800 Bus Sensing Fail Time Delay Int32 Decisecond Deci RW 1 - 6000
42802 Bus Sensing Stable Time Delay Int32 Decisecond Deci RW 1 - 6000
42804 RESERVED
42806 Gen Dead Status Int32 N/A N/A R 0 - 1
42808 Gen Stable Status Int32 N/A N/A R 0 - 1
42810 Gen Fail Status Int32 N/A N/A R 0 - 1
42812 Bus Dead Status Int32 N/A N/A R 0 - 1
42814 Bus Stable Status Int32 N/A N/A R 0 - 1
42816 Bus Fail Status Int32 N/A N/A R 0 - 1
42818 Gen Stable Low Line Scale Factor Float N/A N/A RW 0 - 3
42820 Bus Stable Low Line Scale Factor Float N/A N/A RW 0 - 3
42822-3432 FUTURE USE
Senders
Register Description Type Units
Scaling
Factor
R/W Range
43434 Coolant Temperature Sender Fail Configuration
Type Int32 N/A N/A RW 0 = None
1 = Alarm
2 = Pre-Alarm
43436 Coolant Temperature Sender Fail Activation Delay Int32 Minute N/A RW 5 - 30
43438 Oil Pressure Sender Fail Configuration Type Int32 N/A N/A RW 0 = None
1 = Alarm
2 = Pre-Alarm
43440 Oil Pressure Sender Fail Activation Delay Int32 Second N/A RW 0 - 300
43442 Fuel Level Sender Fail Configuration Type Int32 N/A N/A RW 0 = None
1 = Alarm
2 = Pre-Alarm
43444 Fuel Level Sender Fail Activation Delay Int32 Second N/A RW 0 - 300
43446 Voltage Sensing Fail Configuration Type Int32 N/A N/A RW 0 = None
1 = Alarm
2 = Pre-Alarm
43448 Voltage Sensing Fail Activation Delay Int32 Second N/A RW 0 - 300
43450-498 FUTURE USE Int32 N/A RW
System Configuration and Status
Register Description Type Units
Scaling
Factor
R/W Range
43500 Rated Volts Float Volt N/A RW 1 - 99999
