Winco DGC-2020 - Manual (Page 325)

9400200990 Rev K DGC-2020 Modbus
 Communication
B-49
Register Description Type Units
Scaling
Factor
R/W Range
45576 Gen Kvar B Int32 KiloVAr N/A R (-2147483648) - 2147483647
45578 Gen Kvar C Int32 KiloVAr N/A R (-2147483648) - 2147483647
45580 Gen Kvar Total Int32 KiloVAr N/A R (-2147483648) - 2147483647
45582-749 FUTURE USE
45750 Device Address Int32 N/A N/A RW (-128) - 127
45752 pc Emergency Stop Uint32 N/A N/A RW 0 = Stop
1 = Start
45754 pc Relay Closed Uint32 N/A N/A RW 0 = Stop
1 = Start
45756 Test Buttons Image Uint32 N/A N/A RW 0 - 255
45758 Reserved
45760 Reserved
45762 Embedded Code Version
Number Uint32 N/A N/A R
45764 Boot Code Version
Number Uint32 N/A N/A R
45766 Model Number Uint32 N/A N/A R
45768 Embedded Code Part
Number Uint32 N/A N/A R
45770-999 FUTURE USE
46000 J1939-Transmission Oil
Pressure
Uint32 Raw ECU Parameter
Data
16 kPa/bit gain, 0 kPa
offset
R 0 to +4000 kPa (0 to 580 psi)
46002 J1939-Transmission Oil
Temp
Uint32 Raw ECU Parameter
Data
0.03125 °C/bit gain, −273
°C offset
R −273 to +1735.0 °C
(−459.4 to 3155.0 °F)
46004 J1939-Winding 1 Temp Uint32 Raw ECU Parameter
Data
1 °C/bit gain, −40 °C
offset
R
−40 to +210 °C (−40 to 410 °F)
46006 J1939-Winding 2 Temp Uint32 Raw ECU Parameter
1 °C/bit gain, −40 °C
offset
R −40 to +210 °C (−40 to 410 °F)
46008 J1939-Winding 3 Temp Uint32 Raw ECU Parameter
1 °C/bit gain, −40 °C
offset
R −40 to +210 °C (−40 to 410 °F)
46010 J1939-ECU Temp Uint32 Raw ECU Parameter
Data
0.03125 °C/bit gain, −273
°C offset R −273 to +273 °C (–459 to 523 °F)
46012 J1939-Aux Pressure 1 Uint32 Raw ECU Parameter
Data
16 kPa/bit gain, 0 kPa
offset
R 0 to 4000 kPa
46014 J1939-Aux Pressure 2 Uint32 Raw ECU Parameter
Data
16 kPa/bit gain, 0 kPa
offset
R 0 to 4000 kPa
46016 J1939-Rated Power Uint32 Raw ECU Parameter
Data
0 to 32 127.5 kW (0 to 43
083.7 hp) R 0.5 kW/bit, 0 kW offset
(0.67 hp/bit, 0 hp offset)
