2-7 Wait Input Function
2-17
Fu
nct
ion
s and
Feat
ures
2
SL-V-M-NO2-E

Time chart
Automatic reset mode
Manual reset mode
See "Interlock Function" (page 2-7)
For the SL-V, indication on the bar LED and the center indicators does not change even if the wait input is
activated because the emission on the transmitter continues.
See "Bar LED Indicator" (page 6-2)
SL-V
200 ms max. 200 ms max.
ON
OFF
Wait input
OSSD
ON
OFF
No
interruption
Interruption
200 ms max.
Interlock state
SL-V
ON
OFF
Wait input
OSSD
ON
OFF
No
interruption
Interruption
