KEYENCE SL-V Series - Manual (Page 137)

7-9
S
p
ec
ification
s and
Dimen
sion
s
7
SL-V-M-NO7-E
7-4
Dimensions (SL-VF/VH/VL)
Units: mm
If the length for a single SL-V unit is 710 mm or greater, use a compact E-to-E mounting bracket or an E-
to-E mounting bracket additionally as an intermediate support bracket. The above figures show the exam-
ple for the use of one compact E-to-E bracket.
SL-VF/VH/VL unit
3.9
12
E
A B C
D
5
F
14
9
28
G
4
28
φ5.8 Cable
6-M3 Depth 4.5
26
Transmitter
3.9
12
A B C
D
5 9
28
G
14
4
E
F
28
6-M3 Depth4.5
26
Receiver
NOTE
