7-4 Dimensions (SL-VF/VH/VL)
7-10
S
p
ec
ification
s and
Dimen
sion
s
7
SL-V-M-NO7-E
When two or more intermediate support brackets are installed, be sure to install so as to keep
the distance of 600mm or less between the centers of the intermediate support brackets.

SL-VF Units: mm

SL-VH Units: mm
When using the standard mounting bracket, thin bracket, and L-shaped bracket
Caution
Model
Beam
axes
A:
Length
B:
Detection
height
C:
Protection
height
D: Beam
axis
spacing
E F
G: Intermediate support bracket mounting
position
1st 2nd 3rd 4th
SL-V23F 23 230 220 244
10 5 12
Not needed Not needed Not needed Not needed
SL-V31F 31 310 300 324 Not needed Not needed Not needed Not needed
SL-V39F 39 390 380 404 Not needed Not needed Not needed Not needed
SL-V47F 47 470 460 484 Not needed Not needed Not needed Not needed
SL-V55F 55 550 540 564 Not needed Not needed Not needed Not needed
SL-V63F 63 630 620 644 Not needed Not needed Not needed Not needed
SL-V71F 71 710 700 724 340
±
50 Not needed Not needed Not needed
SL-V79F 79 790 780 804 380
±
50 Not needed Not needed Not needed
SL-V87F 87 870 860 884 420 ± 50 Not needed Not needed Not needed
SL-V95F 95 950 940 964 460 ± 50 Not needed Not needed Not needed
SL-V103F 103 1030 1020 1044 500
±
50 Not needed Not needed Not needed
SL-V111F 111 1110 1100 1124 540
±
50 Not needed Not needed Not needed
SL-V119F 119 1190 1180 1204 380 ± 100 780 ± 100 Not needed Not needed
SL-V127F 127 1270 1260 1284 410 ± 100 830 ± 100 Not needed Not needed
Model
Beam
axes
A:
Length
B:
Detection
height
C:
Protection
height
D: Beam
axis
spacing
E F
G: Intermediate support bracket mounting
position
1st 2nd 3rd 4th
SL-V08H 8 150 140 185
20 5 22.5
Not needed Not needed Not needed Not needed
SL-V12H 12 230 220 265 Not needed Not needed Not needed Not needed
SL-V16H 16 310 300 345 Not needed Not needed Not needed Not needed
SL-V20H 20 390 380 425 Not needed Not needed Not needed Not needed
SL-V24H 24 470 460 505 Not needed Not needed Not needed Not needed
SL-V28H 28 550 540 585 Not needed Not needed Not needed Not needed
SL-V32H 32 630 620 665 Not needed Not needed Not needed Not needed
SL-V36H 36 710 700 745 340 ± 50 Not needed Not needed Not needed
SL-V40H 40 790 780 825 380 ± 50 Not needed Not needed Not needed
SL-V44H 44 870 860 905 420
±
50 Not needed Not needed Not needed
SL-V48H 48 950 940 985 460
±
50 Not needed Not needed Not needed
SL-V52H 52 1030 1020 1065 500 ± 50 Not needed Not needed Not needed
SL-V56H 56 1110 1100 1145 540 ± 50 Not needed Not needed Not needed
SL-V60H 60 1190 1180 1225 380
±
100 780
±
100 Not needed Not needed
SL-V64H 64 1270 1260 1305 410
±
100 830
±
100 Not needed Not needed
SL-V72H 72 1430 1420 1465 460 ± 100 940 ± 100 Not needed Not needed
SL-V80H 80 1590 1580 1625 520 ± 100 1050 ± 100 Not needed Not needed
SL-V88H 88 1750 1740 1785 420
±
100 860
±
100 1300
±
100 Not needed
SL-V96H 96 1910 1900 1945 460
±
100 940
±
100 1420
±
100 Not needed
SL-V104H 104 2070 2060 2105 500 ± 100 1020 ± 100 1540 ± 100 Not needed
SL-V112H 112 2230 2220 2265 430 ± 100 880 ± 100 1320 ± 100 1770 ± 100
SL-V120H 120 2390 2380 2425 460
±
100 940
±
100 1420
±
100 1900
±
100
