Arc Machines, Inc. Model 307 Orbital Tube Welder Training
Document No. 740096 Chapter 8. Page 11.
Rev.A
Weld Schedule - Weld Levels screen
Primary and Background Amps can be adjusted by touching the +1% or
-1% buttons.
Adjust other parameters by touching and typing in new value from
the keyboard. Touch OK to return to the Weld Schedule - Main screen.
Scroll down to view the Primary and Background Pulse Times.
Weld Schedule - Weld Levels screen showing Primary and Background
Pulse times.
Scroll down to
view Primary
and Background
Pulse Times
and Level Times.
In STEP
mode,
Primary
Travel is zero
and travel
takes place
during the
Background
Amps pulse
