Arc Machines, Inc. Model 307 Orbital Tube Welder Training
Document No. 740096 Chapter 3. Page 12
Rev. A
32 Stop of Action To Signify the Stop (of
Action) Function or Con-
trol
ANSI/NEMA
33 Start To Signify the Start (of
Action) Function or Con-
trol
ANSI/NEMA
34 Process Cycle To Signify One Complete
Process Cycle
(Weld Sequence)
ANSI/NEMA
35 Weld Current To Signify Welding Amps
During Process Cycle
ANSI/NEMA
36 Arc Volts To Signify Arc Volts Dur-
ing Process Cycle
ANSI/NEMA
37 Pulse Signifies Pulse Function
or Control
ANSI/NEMA
38 Sequence
Advance
To Signify Advancing to
the Next Sequence Event
(Level)
ANSI/NEMA
39 Sequence
Deadvance
To Signify Returning to
the Previous Sequence
Event (Level)
ANSI/NEMA
40 Air (Gas) Pres-
sure
To Signify Air (or Gas)
Pressure Function or Con-
trol
ANSI/NEMA
41 Purge by Gas To Signify Purging of Air
(by Gas)
ISO
7000-0474
42 Gas Preflow To Signify Gas Preflow
Time (PREPURGE)
ISO 7000-0474
ANSI/NEMA
Table 4. Graphical Symbols used in this Manual
