Document No. 740096 Index. Page 5
Rev.A
Index continued:
U
Upslope , 5.3 , 9.3
USB memory stick , 3.3 , 7.1
V
ventilation
,
16.7
W
Warnings
Disconnect the input power
,
2.1
Do not weld in enclosed areas , 2.3
emission of toxic fumes , 2.2
energized electrical parts , 2.1
factory training is essential , 2.3
fires or explosions , 2.2
High Frequency Radio Wave , 2.1
Magnetic fields
,
2.1
non-flammable protective clothing , 2.2
severe burns from touching newly weld-
ed components
,
2.2
System components are not water-
proof , 2.3
welding arc emits ultra-violet (UV) radi-
ation
,
2.2
welding on sealed containers or pipes ,
2.2
weld
Weld Counter Reset , 10.5
Weld Current. , 1.1
Weld ID , 18.3
weld identification number , 18.2
Weld Mode , 6.4 , 11.2
weld bead smoothness , 17.2
weld data records
,
6.17
,
18.1
,
18.3
printing and exporting , 18.4
Viewing or Exporting , 18.3
Weld head notes
,
18.11
Weld Head Wizard , 18.11
Weld heads
automatic calibration , 13.2
manual calibrataion
,
13.3
Model 8 weld heads , 13.6
water-cooled version of the 9-500 , 4.7
Weld Head Data button
,
6.11
weld head installation , 4.6
weld head selection. , 8.3
Weld heads operated by Model 307 ,
1.1
Weld Logging , 1.2
Weld Problems , 12.4
Weld Procedure Specification (QW-482)
,
19.3
weld record keeping , 10.1
weld schedule , 5.1 , 17.2
Copy and Paste a schedule ,
7.10
delete schedule , 7.9
example Step program , 8.8
Main Weld Screen manual torch , 9.14
paste schedule
,
7.11
rename schedule , 7.8
Single Entry Manual, continuous , 9.5
weld parameters
,
17.2
Weld Schedule - Main screen , 8.5 , 11.1
Weld Schedule - Single Entry , 8.6
Weld Schedule - Weld Levels screen. ,
8.6
weld schedule counter and alert reset ,
10.5
Weld Schedule Main Screen
,
7.2
Weld Schedule Main Screen (Tack
weld) , 8.14
weld schedule name , 7.2 , 8.2
Weld Schedule- Single Entry (manual
torch) , 9.14
Weld Schedule Single Entry, tack weld ,
8.14
Weld Schedule Tacking Values , 8.13
Weld Schedule Weld Levels (tack weld) ,
8.15
Weld Schedule Weld screen , 6.3 , 11.2
Weld Schedule Library , 7.1
Weld Schedule Wizard , 7.7 , 8.1
Weld Time calculator , 6.16
weldability , 17.4
Welding Operator I.D. (see Logon name) ,
6.18
Welding Operator Performance Qualifica-
tion (WOPQ) , 19.3
Welding Operator Qualification to ASME IX
BPVC , 19.3
Welding with the Model 307
Open Last Schedule , 6.3 , 11.1
welds
full penetration welds , 17.2
test coupons , 10.5
trial (partial) weld
,
9.11
weld criteria , 17.2
weld defects , 17.2
Numerics
1/4” OD tubing , 9.12
1/8” OD tubing , 9.12
307 weld schedule sheet
,
19.1
