3–20 Status Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
Notes: For [ ] engineering units, see page 2.
Word Description Bit
B10 = 0 Normal
= 1 Post-decompression Movement Command Error
The module latches this bit at completion of the Plastication Profile if both of the following are true:
S PPC03-B08 is RESET
S SYS15-B15 is RESET
The module also latches this bit if all of the following are true:
S Ram (screw) position equals or exceeds the sum of PPC61 and PPC62
S PPC03-B08 is RESET
S SYS15-B15 is RESET
The module also latches this bit if both of the following are true:
S DYC02-B09 is SET
S SYS15-B15 is RESET
The module also latches this bit if both of the following are true:
S DYC02-B09 is SET
S PSC05 added to the actual ram (screw) position equals or exceeds MCC12
The module unlatches this bit when it decodes a valid Dynamic Command Block with any SET action execution bit
other than DYC02-B08 or DYC02-B09.
B11-15 RFU
SYS14 Miscellaneous
B00 = 0 Normal
= 1 Dual-command Error
The module latches this bit when it decodes a valid Dynamic Command Block having more than one action execution
command bit SET. Bits DYC01-B08 thru B11 and selected bits in DYC02 are the action execution command bits.
The module unlatches this bit when it decodes a valid Dynamic Command Block having one or none of the action ex-
ecution bits SET.
B01 RFU
Command Block Rejection Errors
Module discards and does not attempt to decode any command block associated with a profiled movement in progress.
B02 RFU
B03 = 0 Normal
= 1 Injection Command Block Rejected
The module latches this bit when it receives an INC or IPC for decode and SYS21-B04 is SET.
The module unlatches this bit when it receives an INC or IPC for decode and SYS21-B04 is RESET.
B04 = 0 Normal
= 1 Pack/Hold Command Block Rejected
The module latches this bit when it receives a PKC, HDC, HPC, or PRC for decode and any one of SYS21-B05 -
SYS21-B07 is SET.
The module unlatches this bit when it receives a PKC, HDC, HPC, or PRC for decode and all of SYS21-B05 -
SYS21-B07 are RESET.
B05 = 0 Normal
= 1 Plastication Command Block Rejected
The module latches this bit when it receives a PLC, PPC, or PSC for decode and SYS21-B08 or SYS21-B09 is SET.
The module unlatches this bit when it receives a PLC, PPC, or PSC for decode and both SYS21-B08 and SYS21-B09
are RESET.
B06-13 RFU
B14 = 0 Invalid Input
= 1 Valid Ram (Screw) Position at Input 3 (Used with SYS14-B15 and MCC63 for change-over handshaking, input 3)
The module latches this bit when it detects that a ram (screw) position transducer is connected to input 3.
The module unlatches this bit when it detects that the position transducer has been disconnected during change-over
or that a cavity pressure transducer is permanently connected to input 3.
B15 = 0 Invalid Input
= 1 Valid Ram Cavity Pressure at Input 3 (Used with SYS14-B14 and MCC63 for change-over handshaking, input 3)
The module latches this bit when it detects that a cavity pressure transducer is connected to input 3.
The module unlatches this bit when it detects that the pressure transducer has been disconnected during change-over
or that a ram (screw) position transducer is permanently connected to input 3.
