4–26 Programming Error Codes
Publication 1771-6.5.126 – March 1998
Error Code Description PPC ID = 15
0462 PPC62 is out of range.
if:
then:
MCC13 and MCC14 PPC62 must be within 00000
≤
PPC62
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC62 must be within 00000
≤
PPC62
≤
MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC62 must be within 00000
≤
PPC62
≤
MCC14 – MCC09
MCC14 is non-zero
MCC13 and MCC14 PPC62 must be within 00000
≤
PPC62
≤
MCC10 – MCC09
are both zero
0503 You have selected RPM/Pos execution of the Plastication profile by PPC03-B01 = 1 and
PPC03 -B00 = 0, but your bit pattern in MCC02 indicates that the QI module is not configured
for connection of a screw RPM sensor.
0504 You have selected closed-loop Press/Pos execution for the Plastication Profile by
PPC04-B00 = 0, but your bit patterns in MCC02 and MCC03 indicate that the QI module is not
connected to a ram (screw) pressure transducer.
0507 You have selected RPM/Time execution of the Plastication profile by PPC03-B01 = 1 and
PPC03-B00 = 1, but your bit pattern in MCC02 indicates that the QI module is not configured
for connection of a screw RPM sensor.
0508 You have selected closed-loop Press/Time execution of the Plastication Profile by
PPC04-B01 = 0, but your bit patterns in MCC02 and MCC03 indicate that the QI module is not
connected to a ram (screw) pressure transducer.
0512 You have selected closed-loop RPM/Pos execution of the Plastication profile by
PPC04-B02 = 0, but your bit patterns in MCC02 and MCC03 indicate that the QI module is not
connected to a screw RPM sensor.
0516 You have selected closed-loop RPM/Time execution of the Plastication profile by
PPC04-B03 = 0, but your bit patterns in MCC02 and MCC03 indicate that the QI module is not
connected to a screw RPM sensor.
0600 Your entire Plastication Profile Block has been rejected because the QI module module does
not have a valid Plastication Configuration Block on-board (SYS15-B13 = 0).
0711 PPC11 cannot be 00000 when PPC14 > 00000.
0712 PPC12 cannot be 00000 when PPC14 > 00000.
0715 PPC15 cannot be 00000 when PPC18 > 00000.
0716 PPC16 cannot be 00000 when PPC18 > 00000.
0719 PPC19 cannot be 00000 when PPC22 > 00000.
0720 PPC20 cannot be 00000 when PPC22 > 00000.
0723 PPC23 cannot be 00000 when PPC26 > 00000.
0724 PPC24 cannot be 00000 when PPC26 > 00000.
0727 PPC27 cannot be 00000 when PPC30 > 00000.
0728 PPC28 cannot be 00000 when PPC30 > 00000.
0731 PPC31 cannot be 00000 when PPC34 > 00000.
0732 PPC32 cannot be 00000 when PPC34 > 00000.
0735 PPC35 cannot be 00000 when PPC38 > 00000.
0736 PPC36 cannot be 00000 when PPC38 > 00000.
0739 PPC39 cannot be 00000 when PPC42 > 00000.
0740 PPC40 cannot be 00000 when PPC42 > 00000.
0743 PPC43 cannot be 00000 when PPC46 > 00000.
0744 PPC44 cannot be 00000 when PPC46 > 00000.
0747 PPC47 cannot be 00000 when PPC50 > 00000.
0748 PPC48 cannot be 00000 when PPC50 > 00000.
0815 PPC15 must be 00000 when PPC11 = 00000.
0816 PPC16 must be 00000 when PPC12 = 00000.
0819 PPC19 must be 00000 when PPC15 = 00000.
