2–42 Command Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
Notes: For [ ] engineering units, see page 2.
Word Description Bit
PTC09 Trace #2 selection
B01 Injection position
B02 Injection pressure
B03 Injection velocity
The module will return unscaled injection position data if injection velocity is selected. The process trace screen uses
this position information to calculate and display velocity.
B04 Cavity pressure
B05 Screw RPM
B06 Injection flow valve output
B07 Injection pressure valve output
B08-15 Reserved Do not use.
PTC10 Trace #3 selection
B01 Injection position
B02 Injection pressure
B03 Injection velocity
The module will return unscaled injection position data if injection velocity is selected. The process trace screen uses
this position information to calculate and display velocity.
B04 Cavity pressure
B05 Screw RPM
B06 Injection flow valve output
B07 Injection pressure valve output
PTC11 Trace #4 selection
B01 Injection position
B02 Injection pressure
B03 Injection velocity
The module will return unscaled injection position data if injection velocity is selected. The process trace screen uses
this position information to calculate and display velocity.
B04 Cavity pressure
B05 Screw RPM
B06 Injection flow valve output
B07 Injection pressure valve output
B08 - B15 Reserved Do not use.
PTC12 - 64 RFU
Bit-mapped Control Words
Word Description
RLC01 Block ID = 00011010 (Low byte). High byte reserved for the module. Do not use.
RLC02 - 08 RFU
Injection Profile ERC Values
Word Description
RLC09 Injection Segment 1
RLC10 Injection Segment 2
RLC11 Injection Segment 3
RLC12 Injection Segment 4
RLC13 Injection Segment 5
RLC – Inject ERC Values
Block
