2–31

Command Word/Bit Descriptions

Publication 1771-6.5.126 – March 1998

PKC

Word

Description

PKC09

Output #1 Set-output Value during Profile [19]

PKC10

Output #2 Set-output Value during Profile [19]

PKC11

Output #3 Set-output Value during Profile [19]

PKC12

Output #4 Set-output Value during Profile [19]

PKC13–16

RFU

Output Ramp Rates

The module uses the following ramp rates when moving its outputs
from setpoint to setpoint during the Pack Profile. The module
interprets a ramp rate of zero as a step function ramp (ramp disable).

Word

Description

PKC17

Output #1 Acceleration Ramp Rate during Profile [20]

PKC18

Output #2 Acceleration Ramp Rate during Profile [20]

PKC19

Output #3 Acceleration Ramp Rate during Profile [20]

PKC20

Output #4 Acceleration Ramp Rate during Profile [20]

PKC21-24

RFU

PKC25

Output #1 Deceleration Ramp Rate during Profile [20]

PKC26

Output #2 Deceleration Ramp Rate during Profile [20]

PKC27

Output #3 Deceleration Ramp Rate during Profile [20]

PKC28

Output #4 Deceleration Ramp Rate during Profile [20]

PKC29-40

RFU

Ram (Screw) Pressure Control Limits

Word

Description

PKC41

Ram (Screw) Pressure Min Control Limit [01] Min controllable ram (screw) pressure attainable during any Ram Press/Time Pack
Profile. Module expects this ram (screw) pressure when setting its selected ram (screw ) pressure valve to the %-output in PKC43.

PKC42

Ram (Screw) Pressure Max Control Limit [01] Maxi controllable ram (screw) pressure attainable during any Ram Press/Time Pack
Profile. Module expects this ram (screw) pressure when setting its selected ram (screw) pressure valve to the %-output in PKC44.

PKC43

Selected Ram (Screw) Pressure Valve Output for Minimum [19] 0% CV output percentage that the module uses to drive the se-
lected pressure valve during any Ram Press/Time Pack Profile. The module expects a pressure equal to PKC41 when setting the
selected ram (screw) pressure valve to this %-output during profile execution. Ram Press/Time Pack Profile will be executed as a
reverse-acting algorithm if this entry is greater than PKC44.

PKC44

Selected Ram (Screw) Pressure Valve Output for Maximum [19] 100% CV output percentage that the module uses to drive the
selected pressure valve during any Ram Press/Time Pack Profile. The module expects a pressure equal to PKC42 when setting the
selected ram (screw) pressure valve to this %-output during profile execution. Ram Press/Time Pack Profile will be executed as a
reverse-acting algorithm if this entry is less than PKC43.

Cavity Pressure Control Limits

Word

Description

PKC45

Cavity Pressure Minimum Control Limit [04] Minimum controllable cavity pressure attainable during any Cav Press/Time Pack Pro-
file . The module expects this cavity pressure when setting its selected cavity pressure valve to the %-output in PKC47.

PKC46

Cavity Pressure Maximum Control Limit [04] Maximum controllable cavity pressure attainable during any Cav Press/Time Pack
Profile . The module expects this cavity pressure when setting its selected cavity pressure valve to the %-output in PKC48.

PKC47

Selected Cavity Pressure Valve Output for Minimum [19] 0% CV output percentage that the module uses to drive the selected pres-
sure valve during any Cav Press/Time Pack Profile. The module expects a pressure equal to PKC45 when setting the selected
cavity pressure valve to this %-output during profile execution. The Cav Press/Time Pack Profile will be executed as a reverse-act-
ing algorithm if this entry is greater than PKC48.

PKC48

Selected Cavity Pressure Valve Output for Maximum [19] 100% CV output percentage that the module uses to drive the selected
pressure valve during any Cav Press/Time Pack Profile. The module expects a pressure equal to PKC46 when setting the selected
cavity pressure valve to this %-output during profile execution. The Cav Press/Time Pack Profile will be executed as a reverse-act-
ing algorithm if this entry is less than PKC47.
