3–11 Status Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
PTS
Execution Times
Word Description
PPS57 Plastication Profile Execution Time [21] Total time required for last profile.
PPS58 Post-decompression Movement Execution Time [21] Total time required for last movement.
PPS59 - 60 RFU
Post-decompression Movement Actuals
Word Description
PPS61 Post-decompression Movement Actual Velocity [06] Average ram (screw) velocity during last movement, reported in in.(mm)/s.
PPS62 Post-decompression Movement Actual Pressure [01] Average ram (screw) pressure during last movement.
Shot Size Actual
Word Description
PPS63 Actual Shot Size Extruded [17] Total shot size length drawn at completion of last Plastication Profile.
The module measures total shot size as an incremental length from the End of Hold position (HPS63).
PPS64 RFU
Bit-mapped Status Words
Word Bit Description
PTS01 B00-B07 Block ID = 00001010 (Low byte).
B08-B15 Power start-up and jog execution status (refer to bit description for SYS01)
PTS02 Profile execution status (refer to bit description for SYS02)
PTS03 Miscellaneous status (refer to bit description for SYS03)
PTS04 Watchdog timeout status (refer to bit description for SYS04)
PTS05 Trace selection
If one of PTS05-B01 to B05 is set, PTS15 to PTS64 contain trace data. If PTS05-B15 is set, PTS15 to PTS48 contain
phase/segment start information. Each word contains starting data point (1 - 400) for the listed phase or segment.
If the phase or segment was not executed, this value will be zero.
B00 RFU
B01 Block contains injection position trace data
B02 Block contains trace #1 data
B03 Block contains trace #2 data
B04 Block contains trace #3 data
B05 Block contains trace #4 data
B06-B14 RFU
B15 Block contains phase/segment start information
PTS06 Trace data block number
B00 Block contains trace data points 1 to 50
B01 Block contains trace data points 51 to 100
B02 Block contains trace data points 101 to 150
B03 Block contains trace data points 151 to 200
B04 Block contains trace data points 201 to 250
B05 Block contains trace data points 251 to 300
B06 Block contains trace data points 301 to 350
B07 Block contains trace data points 351 to 400
B08-B15 RFU
PTS07, 08 RFU
PTS – Process Trace
Status Block
