4–5

Programming Error Codes

Publication 1771-6.5.126 – March 1998

Error Code

Description

MCC ID = 1

0428

Your non-zero entry for MCC28 is out of range.
If MCC27 is non-zero, MCC28 must be within MCC27 < MCC28

MCC24

If MCC27 is zero, MCC28 must be within MCC23 < MCC28

MCC24

0431

MCC31 is out of range. Valid range is 00000

MCC31 < MCC32

0432

MCC32 is out of range. Valid range is MCC31 < MCC32

09999

0435

MCC35 is out of range.
If non-zero, MCC35 must be within MCC31 < MCC35

MCC32

0437

MCC37 is out of range. Valid range is 00000

MCC37 < MCC38

0438

MCC38 is out of range. Valid range is MCC37 < MCC38

09999

0441

Your non-zero entry for MCC41 is out of range.
If MCC42 is non-zero, MCC41 must be within MCC37

MCC41 < MCC42

If MCC42 is zero, MCC41 must be within MCC37

MCC41 < MCC38

0442

Your non-zero entry for MCC42 is out of range.
If MCC41 is non-zero, MCC42 must be within MCC41 < MCC42

MCC38

If MCC41 is zero, MCC42 must be within MCC37 < MCC42

MCC38

0445

MCC45 is out of range. Valid range is 00000

MCC45 < MCC46

0446

MCC46 is out of range. Valid range is MCC45 < MCC46

09999

0449

MCC49 is out of range.
If non-zero, MCC49 must be within MCC45 < MCC49

MCC46

0451

MCC51 is out of range. Valid range is 00000

MCC51 < MCC52

0452

MCC52 is out of range. Valid range is MCC51 < MCC52

09999

0455

MCC55 is out of range.
If non-zero, MCC55 must be within MCC51 < MCC55

MCC52

0457

MCC57 is out of range. Valid range is 00000

MCC57 < MCC58

0458

MCC58 is out of range. Valid range is MCC57 < MCC58

20000

0461

MCC61 is out of range.
If non-zero, MCC61 must be within MCC57 < MCC61

MCC58

0502

MCC02-B04 = 1 and/or MCC02-B05 = 1 are illegal conffigurations.

0503

Your bit pattern in the upper byte of MCC03 must be 11111111.

0504

Your bit pattern in the upper byte of MCC04 must be 11111111.

0507

Your settings for MCC02-B03, B04, and B05 indicate that module input #1 or #4 is reserved
for a ram (screw) position transducer. Therefore MCC03-B00 and B01 cannot both = 1.

0511

Your settings for MCC02-B03, B04, and B05 indicate that module input #3 is reserved for a
screw RPM transducer. Therefore MCC03-B00 and B01 cannot both = 1.

0602

Your Module Configuration Command block has been rejected. MCC02-B03 must = 1.

0915

MCC15 is too large.
if:

then:

MCC13 and MCC14

MCC15 must be within MCC13 + MCC15 < MCC14 – MCC15

are both non-zero

MCC13 is zero and

MCC15 must be within MCC09 + MCC15 < MCC14 – MCC15

MCC14 is non-zero

MCC13 is non-zero

MCC15 must be within MCC13 + MCC15 < MCC10 – MCC15

and MCC14 is zero
