2–6 Command Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
Notes: For [ ] engineering units, see page 2.
Word Bit Description
DYC02 B07 = 0 Normal
= 1 Execute Pre-decompression Movement
A false-to-true transition of this bit forces the module to do one of the following, attempted in the order listed.
if: then the module:
any of SYS07-B00 through B05 are SET ignores any movement commands
either of the following are true:
– SYS15-B11 is RESET
– HPC03-B09 is SET and SYS15-B12 is RESET latches SYS13-B08
all of the following are true:
– PRC05 equals zero or SYS15-B12 is RESET
– HPC03-B09 is RESET
– SYS15-B14 is RESET latches SYS13-B09
PRC05 is not zero terminates any action in progress and
starts the Pre-decompression Movement
both of the following are true:
– PRC05 is zero
– HPC03-B09 is SET terminates any action in progress and
sets outputs to PRC33–36
either pair of the following are true:
– PRC05 is zero
or – SYS15-B12 is RESET
– HPC03-B09 is RESET – HPC03-B09 is RESET
terminates any action in progress and
starts the Plastication Profile
B08 = 0 Normal
= 1 Execute Plastication Profile
A false-to-true transition of this bit forces the module to do one of the following, attempted in the order listed.
if: then the module:
any of SYS07-B00 through B05 are SET ignores any profile commands
SYS15-B14 is RESET latches SYS13-B09
all of the following are true:
– ram (screw) position equals or exceeds sum of PPC61 + PPC62
– PPC03-B08 is RESET
– SYS15-B15 is RESET latches SYS13-B10
ram (screw) position is less than the sum of PPC61 + PPC62 terminates any action in progress and
starts the Plastication Profile
both of the following are true:
– ram (screw) position equals or exceeds sum of PPC61 + PPC62
– PPC03-B08 is SET terminates any action in progress and
sets outputs to PLC33–36
all of the following are true:
– ram (screw) position equals or exceeds sum of PPC61 + PPC62
– PPC03-B08 is SET
– PSC05 is not zero terminates any action in progress and
starts Post-decompression Movement
all of the following are true:
– ram (screw) position equals or exceeds sum of PPC61 + PPC62
– PPC03-B08 is SET
– PSC05 is zero terminates any action in progress and
sets outputs to PSC33–36
B09 = 0 Normal
= 1 Execute Post-decompression Movement
A false-to-true transition of this bit forces the module to do one of the following, attempted in the order listed.
if: then the module:
any of SYS07-B00 through B05 are SET ignores any movement commands
SYS15-B15 is RESET latches SYS13-B10
PSC05 is not zero terminates any action in progress and
starts Post-decompression Movement
PSC05 is zero terminates any action in progress and
sets outputs to PSC33–36
B10-14 RFU
