4–23 Programming Error Codes
Publication 1771-6.5.126 – March 1998
Error Code Description PPC ID = 15
0229 PPC29 is out of range. Valid range is 00000
≤
PPC29
≤
09999
0232 PPC32 is out of range. Valid range is 00000
≤
PPC32
≤
09999
0233 PPC33 is out of range. Valid range is 00000
≤
PPC33
≤
09999
0236 PPC36 is out of range. Valid range is 00000
≤
PPC36
≤
09999
0237 PPC37 is out of range. Valid range is 00000
≤
PPC37
≤
09999
0240 PPC40 is out of range. Valid range is PPC40
≤
PPC40
≤
09999
0241 PPC41 is out of range. Valid range is PPC41
≤
PPC40
≤
09999
0244 PPC44 is out of range. Valid range is 00000
≤
PPC44
≤
09999
0245 PPC45 is out of range. Valid range is 00000
≤
PPC45
≤
09999
0248 PPC48 is out of range. Valid range is 00000
≤
PPC48
≤
09999
0249 PPC49 is out of range. Valid range is 00000
≤
PPC49
≤
09999
0251 PPC51 is out of range. Valid range is 00000
≤
PPC51
≤
09999
0410 PPC10 is out of range.
If non-zero, PPC10 must be within PLC41
≤
PPC10
≤
PLC42
0411 PPC11 is out of range.
if:
then:
MCC13 and MCC14 PPC11 must be within 00000
≤
PPC11
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC11 must be within 00000
≤
PPC11
≤
MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC11 must be within 00000
≤
PPC11
≤
MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 PPC11 must be within 00000
≤
PPC11
≤
MCC10 – MCC09
are both zero
0414 PPC14 is out of range.
If non-zero, PPC14 must be within PLC41
≤
PPC14
≤
PLC42
0415 PPC15 is out of range.
if:
then:
MCC13 and MCC14 PPC15 must be within 00000
≤
PPC15
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC15 must be within 00000
≤
PPC15
≤
MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC15 must be within 00000
≤
PPC15
≤
MCC14 – MCC09
MCC14 is non-zero .
MCC13 and MCC14 PPC15 must be within 00000
≤
PPC15
≤
MCC10 – MCC09
are both zero
0418 PPC18 is out of range.
If non-zero, PPC18 must be within PLC41
≤
PPC18
≤
PLC42
0419 PPC19 is out of range.
if:
then:
MCC13 and MCC14 PPC19 must be within 00000
≤
PPC19
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and PPC19 must be within 00000
≤
PPC19
≤
MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and PPC19 must be within 00000
≤
PPC19
≤
MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 PPC19 must be within 00000
≤
PPC19
≤
MCC10 – MCC09
are both zero
0422 PPC22 is out of range.
If non-zero, PPC22 must be within PLC41
≤
PPC22
≤
PLC42
