Command Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
MCC
Word
Bit
Description
MCC02
B04-05
B05
B04
Input Configuration
n ect ontrol (both bit u t be ero)
M
2
4- 5
B
B
Input Conf gurat on
0
0
Inject Control (both bits must be zero)
Input #
Input #
Input #
Input #
Input #1
Input #2
Input #3
Input #4
Ram (Screw) Position
Ram (Screw) Pressure
Screw RPM
Cavity Pressure
B06
MCC02.B06 for QI(A) MCCB02.B06 for QI(B)
Configuration bit
0 = module not configured for screw RPM
1 = tells the module to verify screw RPM configuration or declare a fault
Input 3 must be connected to a sensor and this bit must be set whenever the MCC contains valid screw RPM parameters.
B07
MCC02.B07 for QI(A) MCCB02.B07 for QI(B)
Configuration bit
0 = module not configured for cavity pressure
1 = tells the module to verify cavity pressure configuration or declare a fault
Input 3 must be connected to a sensor and this bit must be set whenever MCC contains valid cavity pressure parameters.
B08
Inhibit (override) loss of sensor protection for screw position input
B09
Inhibit (override) loss of sensor protection for screw pressure input
B10-13
RFU
B14
Inhibit (override) loss of sensor protection for screw RPM input
B15
Inhibit (override) loss of sensor protection for cavity pressure input
MCC03
MCC Input Range Selection
All inputs have the following range selections:
Byy Bxx
Range
0
0
0 to 10 V dc
0
1
1 to 5 V dc
1
0
4 to 20 mA dc
1
1
Not Connected
Use these bit pairs to select the input range:
B01-00
Input #1
B03-02
Input #2
B05-04
Input #3
B07-06
Input #4
B08-15
Important: These bits must be SET.
MCC04
MCC Output Range Selection
All outputs have the following range selections:
Byy Bxx
Range
0
0
–10 to +10 V dc
0
1
0 to +10 V dc
1
0
4 to 20 mA dc
1
1
Not Connected
Use these bit pairs to select the output range:
B01-00
Output #1
B03-02
Output #2
B05-04
Output #3
B07-06
Output #4
B08 – 15
Important: These bits must be SET.
MCC05
Adds percentage offset up to
"10% (–1000 to +1000) to Stop Position of Output #1 (0 V dc or 4 mA).
MCC06
Adds percentage offset up to
"10% (–1000 to +1000) to Stop Position of Output #2 (0 V dc or 4 mA).
MCC07
Adds percentage offset up to
"10% (–1000 to +1000) to Stop Position of Output #3 (0 V dc or 4 mA).
MCC08
Adds percentage offset up to
"10% (–1000 to +1000) to Stop Position of Output #4 (0 V dc or 4 mA).
