3–8 Status Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
Notes: For [ ] engineering units, see page 2.
Word Description
IPS37 Actual Segment 8 Velocity [05] or [06] Average ram (screw) velocity during last Segment 8.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS38 Actual Segment 8 Pressure [01] Average ram (screw) pressure during last Segment 8.
IPS39 Actual Segment 8 Execution Time [21] Time required for last Segment 8.
IPS40 Actual End of Segment 8 Position [12] Ram (Screw) position at completion of last Segment 8.
IPS41 Actual Segment 9 Velocity [05] or [06] Average ram (screw) velocity during last Segment 9.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS42 Actual Segment 9 Pressure [01] Average ram (screw) pressure during last Segment 9.
IPS43 Actual Segment 9 Execution Time [21] Time required for last Segment 9.
IPS44 Actual End of Segment 9 Position [12] Ram (Screw) position at completion of last Segment 9.
IPS45 Actual Segment 10 Velocity [05] or [06] Average ram (screw) velocity during last Segment 10.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS46 Actual Segment 10 Pressure [01] Ram (screw) pressure during last Segment 10.
IPS47 Actual Segment 10 Execution Time [21] Time required for last Segment 10.
IPS48 Actual End of Segment 10 Position [12] Ram (Screw) position at completion of last Segment 10.
IPS49 Actual Segment 11 Velocity [05] or [06] Average ram (screw) velocity during last Segment 11.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS50 Actual Segment 11 Pressure [01] Average ram (screw) pressure during last Segment 11.
IPS51 Actual Segment 11 Execution Time [21] Time required for last Segment 11.
IPS52 RFU
Injection Maximum Pressures
Word Description
IPS53 Maximum Ram (Screw) Pressure During Injection [01] Maximum instantaneous ram (screw) pressure during last profile.
IPS54 Maximum Cavity Pressure During Injection [04] Maximum instantaneous cavity pressure during last profile.
IPS55 - 60 RFU
Injection Transition Actuals
Word Description
IPS61 Actual Time to Transition [21] Total time required for last Injection Profile.
IPS62 Actual Ram (Screw) Position at Transition [12] Instantaneous ram (screw) position at completion of last Injection Profile.
IPS63 Actual Ram (Screw) Pressure at Transition [01] Instantaneous ram (screw) pressure at completion of last Injection Profile.
IPS64 Actual Cavity Pressure at Transition [04] Instantaneous cavity pressure at completion of last Injection Profile.
Bit-mapped Status Words
Word Bit Description
PPS01 Block ID = 00000101 (Low byte). High byte identical to SYS01
PPS02 See SYS02
PPS03 See SYS03
PPS04 See SYS04
PPS05, 06 RFU
PPS – Plastication Profile
Status Block
