Id = 16 – Rockwell Automation 1771-QI,D17716.5.126 PLASTIC MOLD.MODULE User Manual
Page 130
4–28
Programming Error Codes
Publication 1771-6.5.126 – March 1998
ID = 16
PSC – Post-Decompression Configuration Block
Error Code
Description
PSC ID = 16
0208
PSC08 is out of range. Valid range is 00000
≤
PSC08
≤
09999
0209
PSC09 is out of range. Valid range is 00000
≤
PSC09
≤
09999
0210
PSC10 is out of range. Valid range is 00000
≤
PSC10
≤
09999
0211
PSC11 is out of range. Valid range is 00000
≤
PSC11
≤
09999
0212
PSC12 is out of range. Valid range is 00000
≤
PSC12
≤
09999
0213
PSC13 is out of range. Valid range is 00000
≤
PSC13
≤
09999
0214
PSC14 is out of range. Valid range is 00000
≤
PSC14
≤
09999
0215
PSC15 is out of range. Valid range is 00000
≤
PSC15
≤
09999
0216
PSC16 is out of range. Valid range is 00000
≤
PSC16
≤
09999
0217
PSC17 is out of range. Valid range is 00000
≤
PSC17
≤
09999
0218
PSC18 is out of range. Valid range is 00000
≤
PSC18
≤
09999
0219
PSC19 is out of range. Valid range is 00000
≤
PSC19
≤
09999
0220
PSC20 is out of range. Valid range is 00000
≤
PSC20
≤
09999
0221
PSC21 is out of range. Valid range is 00000
≤
PSC21
≤
09999
0222
PSC22 is out of range. Valid range is 00000
≤
PSC22
≤
09999
0223
PSC23 is out of range. Valid range is 00000
≤
PSC23
≤
09999
0224
PSC24 is out of range. Valid range is 00000
≤
PSC24
≤
09999
0225
PSC25 is out of range. Valid range is 00000
≤
PSC25
≤
09999
0226
PSC26 is out of range. Valid range is 00000
≤
PSC26
≤
09999
0227
PSC27 is out of range. Valid range is 00000
≤
PSC27
≤
09999
0228
PSC28 is out of range. Valid range is 00000
≤
PSC28
≤
09999
0229
PSC29 is out of range. Valid range is 00000
≤
PSC29
≤
09999
0230
PSC30 is out of range. Valid range is 00000
≤
PSC30
≤
09999
0231
PSC31 is out of range. Valid range is 00000
≤
PSC31
≤
09999
0232
PSC32 is out of range. Valid range is 00000
≤
PSC32
≤
09999
0233
PSC33 is out of range. Valid range is 00000
≤
PSC33
≤
09999
0234
PSC34 is out of range. Valid range is 00000
≤
PSC34
≤
09999
0235
PSC35 is out of range. Valid range is 00000
≤
PSC35
≤
09999
0236
PSC36 is out of range. Valid range is 00000
≤
PSC36
≤
09999
0237
PSC37 is out of range. Valid range is 00000
≤
PSC37
≤
09999
0238
PSC38 is out of range. Valid range is 00000
≤
PSC38
≤
09999
0239
PSC39 is out of range. Valid range is 00000
≤
PSC39
≤
09999
0240
PSC40 is out of range. Valid range is 00000
≤
PSC40
≤
09999
0405
PSC05 is out of range.
if:
then:
MCC13 and MCC14
PSC05 must be within 00000
≤
PSC05
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and
PSC05 must be within 00000
≤
PSC05
≤
MCC10 – MCC13
MCC14 is zero
MCC13 is zero and
PSC05 must be within 00000
≤
PSC05
≤
MCC14 – MCC09
MCC14 is non-zero
MCC13 and MCC14
PSC05 must be within 00000
≤
PSC05
≤
MCC10 – MCC09
are both zero
0457
PSC57 is out of range.
If non-zero, PSC57 must be within MCC17 < PSC57
≤
MCC18
