4–12 Programming Error Codes
Publication 1771-6.5.126 – March 1998
Error Code Description IPC ID = 9
0441 IPC41 is out of range.
When IPC03-B14 = 1, a non-zero IPC41 must be within INC45
≤
IPC41
≤
INC46
0442 IPC42 is out of range.
If non-zero, IPC42 must be within INC41
≤
IPC42
≤
INC42
0443 IPC43 is out of range.
if:
then:
MCC13 and MCC14 IPC43 must be within 00000
≤
IPC43
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC43 must be within 00000
≤
IPC43
≤
MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC43 must be within 00000
≤
IPC43
≤
MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 IPC43 must be within 00000
≤
IPC43
≤
MCC10 – MCC09
are both zero
0445 IPC45 is out of range.
When IPC03-B14 = 1, a non-zero IPC45 must be within INC45
≤
IPC45
≤
INC46
0446 IPC46 is out of range.
If non-zero, IPC46 must be within INC41
≤
IPC46
≤
INC42
0447 IPC47 is out of range.
if:
then:
MCC13 and MCC14 IPC47 must be within 00000
≤
IPC47
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC47 must be within 00000
≤
IPC47
≤
MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC47 must be within 00000
≤
IPC47
≤
MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 IPC47 must be within 00000
≤
IPC47
≤
MCC10 – MCC09
are both zero
0449 IPC49 is out of range.
When IPC03-B14 = 1, a non-zero IPC49 must be within INC45
≤
IPC49
≤
INC46
0450 IPC50 is out of range.
If non-zero, IPC50 must be within INC41
≤
IPC50
≤
INC42
0451 IPC51 is out of range.
When IPC03-B14 = 1, IPC51 must be within 00000
≤
IPC51
≤
INC46
0452 IPC52 is out of range. Valid range is 00000
≤
IPC52
≤
INC42
0454 IPC54 is out of range. Valid range is INC45
≤
IPC54
≤
INC46
0455 IPC55 is out of range. Valid range is INC41
≤
IPC55
≤
INC42
0456 IPC56 is out of range. Valid range must be compatible with min/max ram (screw) position
limits (MCC09/MCC10) and min/max software travel limits (MCC13/MCC14)
0457 You have selected Pressure Limited Vel/Pos execution for the Injection Profile by
P 3- 1 = and P 3- = 1 ho ever P 57 i out o ran e. IPC03-B01 = 0 and IPC03-B00 = 1; however, IPC57 is out of range.
IPC57 must be within MCC17 < IPC57
≤
MCC18
0458 You have selected Pressure Limited Vel/Pos execution for the Injection Profile by
IPC03-B01 = 0 and IPC03-B00 = 1.
IPC58 is out of range.
if:
then:
MCC13 and MCC14 IPC58 must be within 00000
≤
IPC58
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC58 must be within 00000
≤
IPC58
≤
MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC58 must be within 00000
≤
IPC58
≤
MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 IPC58 must be within 00000
≤
IPC58
≤
MCC10 – MCC09
are both zero
