1–2 Abbreviated Command and Status Blocks
Publication 1771-6.5.126 – March 1998
Word Pro-Set Address Description
Bit-mapped Control Words
DYC01 B34:24 Block ID 00011001 and jog commands
DYC02 B34:25 Action-execution commands
DYC03 B34:26 Miscellaneous commands
DYC04 B34:27 Status request and status clear commands
DYC05-06 B34:28-29 RFU
DYC07 B34:30 Process trace commands
(Series D and newer only)
DYC08 B34:31 Process trace data block request
(Series D and newer only)
Direct Set-output Values
DYC09 N40:121 Output #1
DYC10 N40:122 Output #2
DYC11 N40:123 Output #3
DYC12 N40:124 Output #4
DYC131-16 N40:125-128 RFU
Acceleration Ramp Rates
DYC17 N40:129 Output #1
DYC18 N40:130 Output #2
DYC19 N40:131 Output #3
DYC20 N40:132 Output #4
DYC21-24 N40:133-136 RFU
Deceleration Ramp Rates
DYC25 N40:137 Output #1
DYC26 N40:138 Output #2
DYC27 N40:139 Output #3
DYC28 N40:140 Output #4
DYC29-32 N40:141-144 RFU
DYC33-60 N40:145-172 RFU
Request for Programming Error
DYC61 N40:173 Fetch SYS61 and SYS62
DYC62-64 N40:174-176 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
HDC01 B38:12 Block ID 00000000 00001011
HDC02 B38:13 Selected valve configurations
HDC03-04 B38:14-15 RFU
Expert Response Compensation Percentage
HDC05 N44:181 ERC % minimum cavity pressure
HDC06 N44:182 ERC % minimum ram pressure
HDC07-08 N44:183-184 RFU
Set-output Values for Unselected Valves (During Profile)
HDC09 N44:185 Output #1
HDC10 N44:186 Output #2
HDC11 N44:187 Output #3
HDC12 N44:188 Output #4
HDC13-16 N44:189-192 RFU
DYC – Dynamic
Command Block
HDC – Hold
Configuration Block
