4–13 Programming Error Codes
Publication 1771-6.5.126 – March 1998
Error Code Description IPC ID = 9
0461 Your non-zero entry for IPC61 is out of range.
if:
then:
MCC13 and MCC14 IPC61 must be within 00000
≤
IPC61
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC61 must be within 00000
≤
IPC61
≤
MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC61 must be within 00000
≤
IPC61
≤
MCC14 – MCC09
MCC14 is non-zero .
MCC13 and MCC14 IPC61 must be within 00000
≤
IPC61
≤
MCC10 – MCC09
are both zero
0462 IPC62 is out of range.
If non-zero, IPC62 must be within MCC17
≤
IPC62
≤
MCC18
0463 IPC63 is out of range.
If non-zero, IPC63 must be within MCC57
≤
IPC63
≤
MCC58
0464 IPC64 is out of range.
if:
then:
MCC13 and MCC14 IPC64 must be within 00000
≤
IPC64
≤
MCC14 – MCC13
are both non-zero
MCC13 is non-zero and IPC64 must be within 00000
≤
IPC64
≤
MCC10 – MCC13.
MCC14 is zero
MCC13 is zero and IPC64 must be within 00000
≤
IPC64
≤
MCC14 – MCC09.
MCC14 is non-zero
MCC13 and MCC14 IPC64 must be within 00000
≤
IPC64
≤
MCC10 – MCC09
are both zero
0503 You have selected Pressure Limited Vel/Pos execution for the Injection Profile by
IPC03-B01 = 0 and IPC03-B00 = 1; however, your bit patterns in MCC02 and MCC03 indi-
cate that the QI module is not connected to a ram (screw) pressure transducer.
0504 You have selected closed-loop Press/Pos execution for the Injection Profile by
IPC04-B02 = 0; however, your bit patterns in MCC02 and MCC03 indicate that the QI mod-
ule is not connected to a ram (screw) pressure transducer.
0508 You have selected closed-loop Press/Time execution for the Injection Profile
by IPC04-B03 = 0; however, your bit patterns in MCC02 and MCC03 indicate that the QI
module is not connected to a ram (screw) pressure transducer.
0600 Your entire Injection Profile Block has been rejected because the QI module does not have
a valid Injection Configuration Block on-board (SYS15-B07 = 0).
0711 IPC11 cannot be 00000 because it conflicts with one of: 0711 IPC11 cannot be 00000 because it conflicts with one of:
IPC13 > 00000 when IPC03-B01 = 0
P 13 hen P 3- 1 =
IPC14 > 00000 when IPC03-B01 = 1
0712 IPC12 cannot be 00000 when IPC14 > 00000.
0715 IPC15 cannot be 00000 because it conflicts with one of:
IPC17 > 00000 when IPC03-B01 = 0
IPC18 > 00000 when IPC03-B01 = 1
0716 IPC16 cannot be 00000 when IPC18 > 00000.
0719 IPC19 cannot be 00000 because it conflicts with one of: 0719 IPC19 cannot be 00000 because it conflicts with one of:
IPC21 > 00000 when IPC03-B01 = 0
P 21 hen P 3- 1 =
IPC22 > 00000 when IPC03-B01 = 1
0720 IPC20 cannot be 00000 when IPC22 > 00000.
0723 IPC23 cannot be 00000 because it conflicts with one of: 0723 IPC23 cannot be 00000 because it conflicts with one of:
IPC25 > 00000 when IPC03-B01 = 0
P 25 hen P 3- 1 =
IPC26 > 00000 when IPC03-B01 = 1
0724 IPC24 cannot be 00000 when IPC26 > 00000.
0727 IPC27 cannot be 00000 because it conflicts with one of: 0727 IPC27 cannot be 00000 because it conflicts with one of:
IPC29 > 00000 when IPC03-B01 = 0
P 29 hen P 3- 1 =
IPC30 > 00000 when IPC03-B01 = 1
