3–7 Status Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
IPS
Word Bit Description
B06 Segment 7
B07 Segment 8
B08 Segment 9
B09 Segment 10
B10 Segment 11
B11-B15 RFU
Injection Profile Actuals
Word Description
IPS09 Actual Segment 1 Velocity [05] or [06] Average ram (screw) velocity during last Segment 1.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS10 Actual Segment 1 Pressure [01] Average ram (screw) pressure during last Segment 1.
IPS11 Actual Segment 1 Execution Time [21] Time required for last Segment 1.
IPS12 Actual End of Segment 1 Position [12] Ram (Screw) position at completion of last Segment 1.
IPS13 Actual Segment 2 Velocity [05] or [06] Average ram (screw) velocity during last Segment 2.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS14 Actual Segment 2 Pressure [01] Average ram (screw) pressure during last Segment 2.
IPS15 Actual Segment 2 Execution Time [21] Time required for last Segment 2.
IPS16 Actual End of Segment 2 Position [12] Ram (Screw) position at completion of last Segment 2.
IPS17 Actual Segment 3 Velocity [05] or [06] Average ram (screw) velocity during last Segment 3.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS18 Actual Segment 3 Pressure [01] Average ram (screw) pressure during last Segment 3.
IPS19 Actual Segment 3 Execution Time [21] Time required for last Segment 3.
IPS20 Actual End of Segment 3 Position [12] Ram (Screw) position at completion of last Segment 3.
IPS21 Actual Segment 4 Velocity [05] or [06] Average ram (screw) velocity during last Segment 4.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS22 Actual Segment 4 Pressure [01] Average ram (screw) pressure during last Segment 4.
IPS23 Actual Segment 4 Execution Time [21] Time required for last Segment 4.
IPS24 Actual End of Segment 4 Position [12] Ram (Screw) position at completion of last Segment 4.
IPS25 Actual Segment 5 Velocity [05] or [06] Average ram (screw) velocity during last Segment 5.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS26 Actual Segment 5 Pressure [01] Average ram (screw) pressure during last Segment 5.
IPS27 Actual Segment 5 Execution Time [21] Time required for last Segment 5.
IPS28 Actual End of Segment 5 Position [12] Ram (Screw) position at completion of last Segment 5.
IPS29 Actual Segment 6 Velocity [05] or [06] Average ram (screw) velocity during last Segment 6.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS30 Actual Segment 6 Pressure [01] Average ram (screw) pressure during last Segment 6.
IPS31 Actual Segment 6 Execution Time [21] Time required for last Segment 6.
IPS32 Actual End of Segment 6 Position [12] Ram (Screw) position at completion of last Segment 6.
IPS33 Actual Segment 7 Velocity [05] or [06] Average ram (screw) velocity during last Segment 7.
If IPC03-B14 is RESET, the module reports this average in percent velocity.
If IPC03-B14 is SET, it reports it in in.(mm)/s.
IPS34 Actual Segment 7 Pressure [01] Average ram (screw) pressure during last Segment 7.
IPS35 Actual Segment 7 Execution Time [21] Time required for last Segment 7.
IPS36 Actual End of Segment 7 Position [12] Ram (Screw) position at completion of last Segment 7.
