4–9 Programming Error Codes
Publication 1771-6.5.126 – March 1998
ID = 9
IPC – Injection Profile Block
Error Code Description IPC ID = 9
0207 IPC07 is out of range.
When IPC03-B01 = 0, IPC09 must be within 00000
≤
IPC07
≤
09999
0209 IPC09 is out of range.
When IPC03-B01 = 0, IPC09 must be within 00000
≤
IPC09
≤
09999
0209 IPC09 is out of range.
When IPC03-B01 = 0, IPC09 must be within 00000
≤
IPC09
≤
09999
0212 IPC12 is out of range. Valid range is 00000
≤
IPC12
≤
09999
0213 IPC13 is out of range.
When IPC03-B01 = 0, IPC13 must be within 00000
≤
IPC13
≤
09999
0216 IPC16 is out of range. Valid range is 00000
≤
IPC16
≤
09999
0217 IPC17 is out of range.
When IPC03-B01 = 0, IPC17 must be within 00000
≤
IPC17
≤
09999
0220 IPC20 is out of range. Valid range is 00000
≤
IPC20
≤
09999
0221 IPC21 is out of range.
When IPC03-B01 = 0, IPC21 must be within 00000
≤
IPC21
≤
09999
0224 IPC24 is out of range. Valid range is 00000
≤
IPC24
≤
09999
0225 IPC25 is out of range.
When IPC03-B01 = 0, IPC25 must be within 00000
≤
IPC25
≤
09999
0228 IPC28 is out of range. Valid range is 00000
≤
IPC28
≤
09999
0229 IPC29 is out of range.
When IPC03-B01 = 0, IPC29 must be within 00000
≤
IPC29
≤
09999
0232 IPC32 is out of range. Valid range is 00000
≤
IPC32
≤
09999
0233 IPC33 is out of range.
When IPC03-B01 = 0, IPC33 must be within 00000
≤
IPC33
≤
09999
0236 IPC36 is out of range. Valid range is 00000
≤
IPC36
≤
09999
0237 IPC37 is out of range.
When IPC03-B01 = 0, IPC37 must be within 00000
≤
IPC37
≤
09999
0240 IPC40 is out of range. Valid range is 00000
≤
IPC40
≤
09999
0241 IPC41 is out of range.
When IPC03-B01 = 0, IPC41 must be within 00000
≤
IPC41
≤
09999
0244 IPC44 is out of range. Valid range is 00000
≤
IPC44
≤
09999
0245 IPC45 is out of range.
When IPC03-B01 = 0, IPC45 must be within 00000
≤
IPC45
≤
09999
0248 IPC48 is out of range. Valid range is 00000
≤
IPC48
≤
09999
0249 IPC49 is out of range.
When IPC03-B01 = 0, IPC49 must be within 00000
≤
IPC49
≤
09999
0251 IPC51 is out of range.
When IPC03-B01 = 0, IPC51 must be within 00000
≤
IPC51
≤
09999
0259 IPC59 is out of range. Valid range is 00000
≤
IPC59
≤
00099
0260 IPC60 is out of range. Valid range is 00000
≤
IPC60
≤
09999
0408 IPC08 is out of range.
When IPC03-B14 = 1, a non-zero entry for IPC08 must be within INC23
≤
IPC08
≤
INC24
0409 IPC09 is out of range.
When IPC03-B14 = 1, a non-zero entry for IPC09 must be within INC45
≤
IPC09
≤
INC46
0410 IPC10 is out of range.
If non-zero, IPC10 must be within INC41
≤
IPC10
≤
INC42
