Rockwell Automation 1771-QI,D17716.5.126 PLASTIC MOLD.MODULE User Manual
Page 75
2–43
Command Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
RLC
Word
Description
RLC14
Injection Segment 6
RLC15
Injection Segment 7
RLC16
Injection Segment 8
RLC17
Injection Segment 9
RLC18
Injection Segment 10
RLC19
Injection Segment 11
Pack Profile ERC Values
Word
Description
RLC20
Pack Segment 1
RLC21
Pack Segment 2
RLC22
Pack Segment 3
RLC23
Pack Segment 4
RLC24
Pack Segment 5
Hold Profile ERC Values
Word
Description
RLC25
Hold Segment 1
RLC26
Hold Segment 2
RLC27
Hold Segment 3
RLC28
Hold Segment 4
RLC29
Hold Segment 5
Plastication Profile ERC Values
Word
Description
RLC30
Plastication Segment 1
RLC31
Plastication Segment 2
RLC32
Plastication Segment 3
RLC33
Plastication Segment 4
RLC34
Plastication Segment 5
RLC35
Plastication Segment 6
RLC36
Plastication Segment 7
RLC37
Plastication Segment 8
RLC38
Plastication Segment 9
RLC39
Plastication Segment 10
RLC40
Plastication Segment 11
RLC41 - 64
RFU
