2–35 Command Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
PPC
Profile Pressure Alarm Setpoint
Word Description
PLC57 Profile High Pressure Alarm Setpoint [01] The module compares real-time ram (screw) pressure against this entry when executing
the Plastication Profile. The module sets alarm status bit SYS06-B07 when ram (screw) pressure equals or exceeds this entry
during the Plastication Profile. A zero entry inhibits SYS06-B07.
PLC58 - 64 RFU
Bit-mapped Control Words
Word Bit Description
PPC01 Block ID = 00001111 (Low byte). High byte reserved for the module. Do not use.
PPC02 RFU
PPC03 Configuration Selections
B00-B01 Profile Algorithm Selection
B01
B00
0 0 Ram (Screw) Press/Pos
0 1 Ram (Screw) Press/Time
1 0 RPM/Pos
1 1 RPM/Time
B02-B07 RFU
B08 Plastication/Post-decompression Logical Bridge Selection End of Plastication Profile
= 0 Start Post-decompression Movement at End of Plastication Profile
= 1 Stop and Set-output at End of Plastication Profile
Module checks the state of this pause bit at completion of Plastication Profile to determine what further action to take:
if:
then the module:
SET sets its outputs to PLC33–36
RESET, SYS15-B15 = 1, immediately begins the Post-decompression Movement
and PSC05 > 00000
RESET, SYS15-B15 = 1,
sets its outputs to PSC33–36
and PRC05 = 00000
RESET and SYS15-B12 = 0
sets its outputs to zero and latches SYS13-B10
B09-B11 RFU
Profile Offset Sign Selection
B12 = 0 Plastication RPM Profile Offset is Positive
= 1 Plastication RPM Profile Offset is Negative
B13 = 0 Plastication Pressure Profile Offset is Positive
= 1 Plastication Pressure Profile Offset is Negative
B14-B15 RFU
PPC04 Configuration Selections
Open/Closed Loop Selection
B00 = 0 Press/Pos Plastication Profiles Closed Loop
= 1 Press/Pos Plastication Profiles Open Loop
B01 = 0 Press/Time Plastication Profiles Closed Loop
= 1 Press/Time Plastication Profiles Open Loop
B02 = 0 RPM/Pos Plastication Profiles Closed Loop
= 1 RPM/Pos Plastication Profiles Open Loop
B03 = 0 RPM/Time Plastication Profiles Closed Loop
= 1 RPM/Time Plastication Profiles Open Loop
B04-B07 RFU
ERC Enabled/Disabled Selection
B08 = 0 Press/Pos Plastication ERC On
= 1 Press/Pos Plastication ERC Off
B09 = 0 Press/Time Plastication ERC On
= 1 Press/Time Plastication ERC Off
PPC – Plastication
Profile Block
