4–17 Programming Error Codes
Publication 1771-6.5.126 – March 1998
Error Code Description HDC ID = 11
0230 HDC30 is out of range. Valid range is 00000
≤
HDC30
≤
09999
0231 HDC31 is out of range. Valid range is 00000
≤
HDC31
≤
09999
0232 HDC32 is out of range. Valid range is 00000
≤
HDC32
≤
09999
0233 HDC33 is out of range. Valid range is 00000
≤
HDC33
≤
09999
0234 HDC34 is out of range. Valid range is 00000
≤
HDC34
≤
09999
0235 HDC35 is out of range. Valid range is 00000
≤
HDC35
≤
09999
0236 HDC36 is out of range. Valid range is 00000
≤
HDC36
≤
09999
0237 HDC37 is out of range. Valid range is 00000
≤
HDC37
≤
09999
0238 HDC38 is out of range. Valid range is 00000
≤
HDC38
≤
09999
0239 HDC39 is out of range. Valid range is 00000
≤
HDC39
≤
09999
0240 HDC40 is out of range. Valid range is 00000
≤
HDC40
≤
09999
0243 HDC43 is out of range. Valid range is 00000
≤
HDC43
≤
09999
0244 HDC44 is out of range. Valid range is 00000
≤
HDC44
≤
09999
0247 HDC47 is out of range. Valid range is 00000
≤
HDC47
≤
09999
0248 HDC48 is out of range. Valid range is 00000
≤
HDC48 > 09999
0249 HDC49 is out of range. Valid range is 00000
≤
HDC49
≤
09999
0250 HDC50 is out of range. Valid range is 00000
≤
HDC50
≤
09999
0251 HDC51 is out of range. Valid range is 00000
≤
HDC51
≤
09999
0252 HDC52 is out of range. Valid range is 00000
≤
HDC52
≤
09999
0253 HDC53 is out of range. Valid range is 00000
≤
HDC53
≤
09999
0254 HDC54 is out of range. Valid range is 00000
≤
HDC54
≤
09999
0253 HDC53 is out of range. Valid range is 00000
≤
HDC53
≤
09999
0254 HDC54 is out of range. Valid range is 00000
≤
HDC54
≤
09999
0343 HDC43 is equal to HDC44. They must not be equal.
0347 HDC47 is equal to HDC48. They must not be equal.
0441 HDC41 is out of range. Valid range is 00000
≤
HDC41 < HDC42
0442 HDC42 is out of range. Valid range is HDC41 < HDC42
≤
09999
0445 HDC45 is out of range. Valid range is 00000
≤
HDC45 < HDC46
0446 HDC46 is out of range. Valid range is HDC45 < HDC46
≤
20000
0457 HDC57 is out of range.
If non-zero, HDC57 must be within MCC17 < HDC57
≤
MCC18
0458 HDC58 is out of range.
If non-zero, HDC58 must be within MCC57 < HDC58
≤
MCC58
0502 Your bit pattern in HDC02-B02, -B01, and -B00 indicates a selected cavity pressure control
valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in HDC02-B06, -B05, and -B04 indicates a selected ram (screw) pressure
control valve that is unconnected according to your entries in MCC02 and MCC04.
ID = 12
HPC – Pack/Hold Profile Block
Error Code Description HPC ID = 12
0211 HPC11 is out of range. Valid range is 00000
≤
HPC11
≤
09999
0214 HPC14 is out of range. Valid range is 00000
≤
HPC14
≤
09999
0217 HPC17 is out of range. Valid range is 00000
≤
HPC17
≤
09999
0220 HPC20 is out of range. Valid range is 00000
≤
HPC20
≤
09999
0223 HPC23 is out of range. Valid range is 00000
≤
HPC23
≤
09999
0228 HPC28 is out of range. Valid range is 00000
≤
HPC28
≤
09999
