2–20

Command Word/Bit Descriptions

Publication 1771-6.5.126 – March 1998

Notes: For [ ] engineering units, see page 2.

Word

Bit

Description

IPC04

Selections to Inhibit Closed Loop Up To Shot Size

B04

= 0 Allow Closed Loop Vel/Pos During Entire Profile
= 1 Inhibit Closed Loop Vel/Pos Until 100% Shot Size
if:

then the module:

SET when IPC04-B00 is SET

inhibits closed-loop control of all Vel/Pos Injection Profiles until ram
(screw) position equals or is less than the 100% shot size position

RESET when IPC04-B00 is SET

performs closed-loop control of the entire Vel/Pos Injection Profile.

If IPC04-B00 is RESET

ignores the state of this bit.

B05

= 0 Allow Closed Loop LimVel/Pos During
= 1 Inhibit Closed Loop LimVel/Pos Until 100%
if:

then the module:

SET when IPC04-B01 is SET

inhibits closed-loop control of all LimVel/Pos Injection Profiles until ram
(screw) position equals or is less than the 100% shot size position

RESET when IPC04-B01 is SET

performs closed-loop control of the entire LimVel/Pos Injection Profile

IPC04-B01 is RESET

ignores the state of this bit

B06

= 0 Allow Closed Loop Press/Pos During Entire Profile
= 1 Inhibit Closed Loop Press/Pos Until 100% Shot Size
if:

then the module:

SET when IPC04-B02 is SET

inhibits closed-loop control of all Press/Pos Injection Profiles until ram
(screw) position equals or is less than the 100% shot size position

RESET when IPC04-B02 is SET

performs closed-loop control of the entire Press/Pos Injection Profile

IPC04-B02 is RESET

ignores the state of this bit

B07

= 0 Allow Closed Loop Press/Time During Entire Profile
= 1 Inhibit Closed Loop Press/Time Until 100% Shot Size
if:

then the module:

SET when IPC04-B03 is SET

inhibits closed-loop control of all Press/Time Injection Profiles until ram
(screw) positionequals or is less than the 100% shot size position

RESET when IPC04-B03 is SET

performs closed-loop control of the entire Press/Time Injection Profile

IPC04-B03 is RESET

ignores the state of this bit

ERC Enabled/Disabled Selection

B08

= 0 Vel/Pos ERC On
= 1 Vel/Pos ERC Off

B09

= 0 Vel/Pos (limited) ERC On
= 1 Vel/Pos (limited) ERC Off

B10

= 0 Press/Pos ERC On
= 1 Press/Pos ERC Off

B11

= 0 Press/Time ERC On
= 1 Press/Time ERC Off

B12-15

RFU

IPC05 - 06

RFU

Co-injection Parameters

Word

Description

IPC07

IPC07 for QI(A) IPCB07 for QI(B)
Time delay for resuming injection after reaching screw position (IPC08). Units are 0.01 sec. Zero disables the time delay.

IPC08

IPC08 for QI(A) IPCB08 for QI(B)
Screw position at which opposite injection starts after suspension.
