4–29 Programming Error Codes
Publication 1771-6.5.126 – March 1998
Error Code Description PSC ID = 16
0905 PSC05 is too large.
if:
then:
MCC13 and MCC14 PSC05 must be within MCC13 + PPC61 + PPC62 + PSC05
are both non-zero
≤
MCC14
MCC13 is zero and PSC05 must be within MCC09 + PPC61 + PPC62 + PSC05
MCC14 is non-zero
≤
MCC14
MCC13 is non-zero and PSC05 must be within MCC13 + PPC61 + PPC62 + PSC05
MCC14 is zero
≤
MCC10
MCC13 and MCC14 PSC05 must be within MCC09 + PPC61 + PPC62 + PSC05
are both zero
≤
MCC10
ID = 25
DYC – Dynamic Command Block
Error Code Description DYC ID = 25
0209 DYC09 is out of range. Valid range is 00000
≤
DYC09
≤
09999
0210 DYC10 is out of range. Valid range is 00000
≤
DYC10
≤
09999
0211 DYC11 is out of range. Valid range is 00000
≤
DYC11
≤
09999
0212 DYC12 is out of range. Valid range is 00000
≤
DYC12
≤
09999
0213 DYC13 is out of range. Valid range is 00000
≤
DYC13
≤
09999
0214 DYC14 is out of range. Valid range is 00000
≤
DYC14
≤
09999
0215 DYC15 is out of range. Valid range is 00000
≤
DYC15
≤
09999
0216 DYC16 is out of range. Valid range is 00000
≤
DYC16
≤
09999
0217 DYC17 is out of range. Valid range is 00000
≤
DYC17
≤
09999
0218 DYC18 is out of range. Valid range is 00000
≤
DYC18
≤
09999
0219 DYC19 is out of range. Valid range is 00000
≤
DYC19
≤
09999
0220 DYC20 is out of range. Valid range is 00000
≤
DYC20
≤
09999
0221 DYC21 is out of range. Valid range is 00000
≤
DYC21
≤
09999
0222 DYC22 is out of range. Valid range is 00000
≤
DYC22
≤
09999
0223 DYC23 is out of range. Valid range is 00000
≤
DYC23
≤
09999
0224 DYC24 is out of range. Valid range is 00000
≤
DYC24
≤
09999
0225 DYC25 is out of range. Valid range is 00000
≤
DYC25
≤
09999
0226 DYC26 is out of range. Valid range is 00000
≤
DYC26
≤
09999
0227 DYC27 is out of range. Valid range is 00000
≤
DYC27
≤
09999
0228 DYC28 is out of range. Valid range is 00000
≤
DYC28
≤
09999
0229 DYC29 is out of range. Valid range is 00000
≤
DYC29
≤
09999
0230 DYC30 is out of range. Valid range is 00000
≤
DYC30
≤
09999
0231 DYC31 is out of range. Valid range is 00000
≤
DYC31
≤
09999
0232 DYC32 is out of range. Valid range is 00000
≤
DYC32
≤
09999
0261 DYC61 is out of range. Valid range is 00000
≤
DYC61
≤
00027
0503 DYC03.B05 selected an invalid cavity input
0569 DYC03.B05 was switched during time delay IPC07 or while profile was active
ID = 26
RLC – Inject ERC Values Block
Error Code Description RLC ID = 26
0209 RLC09 is out of range. Valid range is 00000
≤
RLC09
≤
09999
0210 RLC10 is out of range. Valid range is 00000
≤
RLC10
≤
09999
0211 RLC11 is out of range. Valid range is 00000
≤
RLC11
≤
09999
