4–30 Programming Error Codes
Publication 1771-6.5.126 – March 1998
Error Code Description RLC ID = 26
0212 RLC12 is out of range. Valid range is 00000
≤
RLC12
≤
09999
0213 RLC13 is out of range. Valid range is 00000
≤
RLC13
≤
09999
0214 RLC14 is out of range. Valid range is 00000
≤
RLC14
≤
09999
0215 RLC15 is out of range. Valid range is 00000
≤
RLC15
≤
09999
0216 RLC16 is out of range. Valid range is 00000
≤
RLC16
≤
09999
0217 RLC17 is out of range. Valid range is 00000
≤
RLC17
≤
09999
0218 RLC18 is out of range. Valid range is 00000
≤
RLC18
≤
09999
0219 RLC19 is out of range. Valid range is 00000
≤
RLC19
≤
09999
0220 RLC20 is out of range. Valid range is 00000
≤
RLC20
≤
09999
0221 RLC21 is out of range. Valid range is 00000
≤
RLC21
≤
09999
0222 RLC22 is out of range. Valid range is 00000
≤
RLC22
≤
09999
0223 RLC23 is out of range. Valid range is 00000
≤
RLC23
≤
09999
0224 RLC24 is out of range. Valid range is 00000
≤
RLC24
≤
09999
0225 RLC25 is out of range. Valid range is 00000
≤
RLC25
≤
09999
0226 RLC26 is out of range. Valid range is 00000
≤
RLC26
≤
09999
0227 RLC27 is out of range. Valid range is 00000
≤
RLC27
≤
09999
0228 RLC28 is out of range. Valid range is 00000
≤
RLC28
≤
09999
0229 RLC29 is out of range. Valid range is 00000
≤
RLC29
≤
09999
0230 RLC30 is out of range. Valid range is 00000
≤
RLC30
≤
09999
0231 RLC31 is out of range. Valid range is 00000
≤
RLC31
≤
09999
0232 RLC32 is out of range. Valid range is 00000
≤
RLC32
≤
09999
0233 RLC33 is out of range. Valid range is 00000
≤
RLC33
≤
09999
0234 RLC34 is out of range. Valid range is 00000
≤
RLC34
≤
09999
0235 RLC35 is out of range. Valid range is 00000
≤
RLC35
≤
09999
0236 RLC36 is out of range. Valid range is 00000
≤
RLC36
≤
09999
0237 RLC37 is out of range. Valid range is 00000
≤
RLC37
≤
09999
0238 RLC38 is out of range. Valid range is 00000
≤
RLC38
≤
09999
0239 RLC39 is out of range. Valid range is 00000
≤
RLC39
≤
09999
0240 RLC40 is out of range. Valid range is 00000
≤
RLC40
≤
09999
ID = 28
PTC – Process Trace Configuration Block
Error Code Description PTC ID = 28
0205 PTC05 (trigger delay) is out of range.
Valid range is 00000
≤
PTC05
≤
09999.
0206 PTC06 (trigger position) is out of range.
Valid range is IPC61
≤
PTC06
≤
PPC61 + PPC62 + PSC05
0207 PTC07 (sample rate) is out of range.
Valid range is 00002
≤
PTC07
≤
00230.
0407 PTC07 (sample rate) is not an even number.
0208 PTC08 (trace #1 selection) is invalid.
0209 PTC09 (trace #2 selection) is invalid.
0210 PTC10 (trace #3 selection) is invalid.
0211 PTC11 (trace #4 selection) is invalid.
