1–13 Abbreviated Command and Status Blocks
Publication 1771-6.5.126 – March 1998
Acceleration Ramp Rates
PRC17 N44:313 Output #1
PRC18 N44:314 Output #2
PRC19 N44:315 Output #3
PRC20 N44:316 Output #4
Deceleration Ramp Rates
PRC25 N44:321 Output #1
PRC26 N44:322 Output #2
PRC27 N44:323 Output #3
PRC28 N44:324 Output #4
PRC29-32 N44:325-328 RFU
End of Movement Set-output Values
PRC33 N44:329 Output #1
PRC34 N44:330 Output #2
PRC35 N44:331 Output #3
PRC36 N44:332 Output #4
PRC37-56 N44:333-352 RFU
Setpoint for Movement Pressure Alarm
PRC57 N44:353 High pressure alarm
PRC58-64 N44:354-360 RFU
Word Pro-Set Address Description
Bit-mapped Control Words
PSC01 B38:32 Block ID 00000000 00010000
PSC02-04 B38:33-35 RFU
Movement Length
PSC05 N44:481 Length of post-decompress movement
PSC06-07 N44:482-483 RFU
Watchdog Timer
PSC08 N44:484 Movement timer preset
Set-output Values During Movement
PSC09 N44:485 Output #1
PSC10 N44:486 Output #2
PSC11 N44:487 Output #3
PSC12 N44:488 Output #4
PSC13-16 N44:489-492 RFU
Acceleration Ramp Rates
PSC17 N44:493 Output #1
PSC18 N44:494 Output #2
PSC19 N44:495 Output #3
PSC20 N44:496 Output #4
PSC21-24 N44:497-500 RFU
Deceleration Ramp Rates
PSC25 N44:501 Output #1
PSC26 N44:502 Output #2
PSC27 N44:503 Output #3
PSC28 N44:504 Output #4
PSC29-32 N44:505-508 RFU
PSC –
Post-decompression
Configuration Block
