2–40

Command Word/Bit Descriptions

Publication 1771-6.5.126 – March 1998

Notes: For [ ] engineering units, see page 2.

Bit-mapped Control Words

Word

Bit

Description

PSC01

Block ID = 00010000 (Low byte). High byte reserved for the module. Do not use.

PSC02 - 04

RFU

Movement Length

Word

Description

PSC05

Incremental Movement Length [17] When the module starts the Post-decompression Movement, it adds this entry to the sum of
cushion size (PPC61) + shot size (PPC62) to establish the End of Post-decompression ram (screw) position. The module uses End
of Post-decompression position as termination point of all Post-decompression Movements.

PSC06 - 07

RFU

Watchdog Timer

Word

Description

PSC08

Movement Watchdog Timer Preset [21] When the module starts the Post-decompression Movement, it:

S starts an internal Movement Watchdog timer

S stops timer and resets accumulated value to zero (after reporting total execution time in PPS58) when it completes the movement

S sets master status bit SYS04-B09 when the accumulated value of this timer equals or exceeds this entry.
A zero entry inhibits SYS04-B09.

Movement Set-output Values

When the module starts the Post-decompression Movement, it:

uses ramp rates PRC17-20 and PRC25-28 to ramp outputs

sets its outputs to the values listed below

Word

Description

PSC09

Output #1 Set-output Value during Movement [19]

PSC10

Output #2 Set-output Value during Movement [19]

PSC11

Output #3 Set-output Value during Movement [19]

PSC12

Output #4 Set-output Value during Movement [19]

PSC13-16

RFU

Output Ramp Rates

The module uses the following ramp rates when moving its outputs
between setpoints during Post-decompression Movement. The module
interprets a ramp rate of zero as a step function ramp (ramp disable).

Word

Description

PSC17

Output #1 Acceleration Ramp Rate during Movement [20]

PSC18

Output #2 Acceleration Ramp Rate during Movement [20]

PSC19

Output #3 Acceleration Ramp Rate during Movement [20]

PSC20

Output #4 Acceleration Ramp Rate during Movement [20]

PSC21-24

RFU

PSC25

Output #1 Deceleration Ramp Rate during Movement [20]

PSC26

Output #2 Deceleration Ramp Rate during Movement [20]

PSC27

Output #3 Deceleration Ramp Rate during Movement [20]

PSC28

Output #4 Deceleration Ramp Rate during Movement [20]

PSC29-32

RFU

PSC – Post-decompression
Configuration Block
