2–8 Command Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
Notes: For [ ] engineering units, see page 2.
DYC04 Status Request Commands Y 4
Bits DYC04-B00 - DYC04-B07 are the eight command bits available to request the Status Blocks that the module returns with
the next BTR to the PLC processor. The module does not respond to any bit associated with an unsupported status block
(based on Module I/O configuration). The module defaults to returning System Status Block (SYS) if none of these eight bits are
set or if the last BTW received at the module was not the Dynamic Command Block (DYC). If more than one of these eight bits
are set, the module prioritizes BTR service by responding to the lowest-numbered bit.
B00 RFU
B01 = 0 Normal
= 1 Return IPS with next BTR
B02 = 0 Normal
= 1 Return HPS with next BTR
B03 = 0 Normal
= 1 Return PPS with next BTR
B04, 05 RFU
B06 = 0 Normal
= 1 Return RLS with next BTR
B07 RFU
Profile Status Block Clear Commands
B08 RFU
B09 = 0 Normal
= 1 Clear IPS
A false-to-true transition of this bit forces the module to zero all words in IPS buffer (except Master Status Words IPS01 - IPS04).
The module does not respond to this bit if the IPS is an unsupported status block based upon Module I/O configuration.
B10 = 0 Normal
= 1 Clear HPS
A false-to-true transition of this bit forces module to zero all words in HPS buffer (except Master Status Words HPS01 – HPS04)
The module does not respond to this bit if the HPS is an unsupported status block based upon Module I/O configuration.
B11 = 0 Normal
= 1 Clear PPS
A false-to-true transition of this bit forces module to zero all words in PPS buffer (except Master Status Words PPS01 - PPS04).
The module does not respond to this bit if the PPS is an unsupported status block based upon Module I/O configuration.
B12-14 RFU
B15
= 0 Normal
= 1 Clear PTS (Same description as B13, but for PTS.)
DYC05 ERC Re-initialize Commands Y 5
B00-03 RFU
B04 = 0 Normal
= 1 Re-initialize Injection Profile ERC Values
A false-to-true transition of this bit forces module to re-initialize the 11 ERC values associated with the Injection Profile.
B05 = 0 Normal
= 1 Re-initialize Pack Profile ERC Values
A false-to-true transition of this bit forces the module to re-initialize the five ERC values associated with Pack Profile.
B06 = 0 Normal
= 1 Re-initialize Hold Profile ERC Values
A false-to-true transition of this bit forces the module to re-initialize the five ERC values associated with the Hold Profile.
B07 = 0 Normal
= 1 Open
B08 = 0 Normal
= 1 Re-initialize Plastication Profile ERC Values
A false-to-true transition of this bit forces module to re-initialize the 11 ERC values associated with Plastication Profile.
B09-14 RFU
B15 = 0 Normal
= 1 Re-initialize All ERC Values
A false-to-true transition of this bit forces the module to re-initialize the 62 ERC values associated with all profiles.
DYC06 RFU
