1–10

Abbreviated Command and Status Blocks

Publication 1771-6.5.126 – March 1998

Profile Tuning Constants

PKC49

N44:165

Proportional gain, ram (screw) pressure control

PKC50

N44:166

Integral gain, ram (screw) pressure control

PKC51

N44:167

Derivative gain, ram (screw) pressure control

PKC52

N44:168

Proportional gain, cavity pressure control

PKC53

N44:169

Integral gain, cavity pressure control

PKC54

N44:170

Derivative gain, cavity pressure control

Setpoints for Profile Pressure Alarms

PKC55-56

N44:171-172

RFU

PKC57

N44:173

High ram (screw) pressure alarm

PKC58

N44:174

High cavity pressure alarm

PKC59-64

N44:175-180

RFU

Word

Pro-Set Address

Description

Bit-mapped Control Words

PLC01

B38:24

Block ID 00000000 00001110

PLC02

B38:25

Selected valve configurations

PLC03-04

B38:26-27

RFU

Expert Response Compensation Percentage

PLC05

N44:361

ERC % minimum RPM

PLC06

N44:362

ERC % minimum pressure

PLC07

N44:363

RFU

Watchdog Timer

PLC08

N44:364

Profile timer preset

Set-output Values for Unselected Valves (During Profile)

PLC09

N44:365

Output #1

PLC10

N44:366

Output #2

PLC11

N44:367

Output #3

PLC12

N44:368

Output #4

PLC13-16

N44:369-372

RFU

Acceleration Ramp Rates

PLC17

N44:373

Output #1

PLC18

N44:374

Output #2

PLC19

N44:375

Output #3

PLC20

N44:376

Output #4

PLC21-24

N44:377-380

RFU

Deceleration Ramp Rates

PLC25

N44:381

Output #1

PLC26

N44:382

Output #2

PLC27

N44:383

Output #3

PLC28

N44:384

Output #4

PLC29-32

N44:385-388

RFU

End of Profile Set-output Values

PLC33

N44:389

Output #1

PLC34

N44:390

Output #2

PLC35

N44:391

Output #3

PLC36

N44:392

Output #4

PLC37-40

N44:393-396

RFU

PLC – Plastication
Configuration Block
