4–21

Programming Error Codes

Publication 1771-6.5.126 – March 1998

Error Code

Description

PRC ID = 13

0405

PRC05 is out of range.
if:

then:

MCC13 and MCC14

PRC05 must be within 00000

PRC05

MCC14 – MCC13

are both non-zero

MCC13 is non-zero and

PRC05 must be within 00000

PRC05

MCC10 – MCC13

MCC14 is zero

MCC13 is zero and

PRC05 must be within 00000

PRC05

MCC14 – MCC09

MCC14 is non-zero

MCC13 and MCC14

PRC05 must be within 00000

PRC05

MCC10 – MCC09

are both zero

0457

PRC57 is out of range.
If non-zero, PRC57 must be within MCC17 < PRC57

MCC18

0905

PRC05 is too large.
if:

then:

MCC13 and MCC14

PRC05 must be within MCC13 + PPC61 + PRC05

MCC14

are both non-zero

MCC13 is zero and

PRC05 must be within MCC09 + PPC61 + PRC05

MCC14

MCC14 is non-zero

MCC13 is non-zero and

PRC05 must be within MCC13 + PPC61 + PRC05

MCC10

MCC14 is zero

MCC13 and MCC14

PRC05 must be within MCC09 + PPC61 + PRC05

MCC10

are both zero

ID = 14

PLC – Plastication Configuration Block

Error Code

Description

PLC ID = 14

0206

PLC06 is out of range. Valid range is 00000

PLC06

09999

0208

PLC08 is out of range. Valid range is 00000

PLC08

09999

0209

PLC09 is out of range. Valid range is 00000

PLC09

09999

0210

PLC10 is out of range. Valid range is 00000

PLC10

09999

0211

PLC11 is out of range. Valid range is 00000

PLC11

09999

0212

PLC12 is out of range. Valid range is 00000

PLC12

09999

0213

PLC13 is out of range. Valid range is 00000

PLC13

09999

0214

PLC14 is out of range. Valid range is 00000

PLC14

09999

0215

PLC15 is out of range. Valid range is 00000

PLC15

09999

0216

PLC16 is out of range. Valid range is 00000

PLC16

09999

0217

PLC17 is out of range. Valid range is 00000

PLC17

09999

0218

PLC18 is out of range. Valid range is 00000

PLC18

09999

0219

PLC19 is out of range. Valid range is 00000

PLC19

09999

0220

PLC20 is out of range. Valid range is 00000

PLC20

09999

0221

PLC21 is out of range. Valid range is 00000

PLC21

09999

0222

PLC22 is out of range. Valid range is 00000

PLC22

09999

0223

PLC23 is out of range. Valid range is 00000

PLC23

09999

0224

PLC24 is out of range. Valid range is 00000

PLC24

09999

0225

PLC25 is out of range. Valid range is 00000

PLC25

09999

0226

PLC26 is out of range. Valid range is 00000

PLC26

09999

0227

PLC27 is out of range. Valid range is 00000

PLC27

09999

0228

PLC28 is out of range. Valid range is 00000

PLC28

09999

0229

PLC29 is out of range. Valid range is 00000

PLC29

09999
