4–6 Programming Error Codes
Publication 1771-6.5.126 – March 1998
Error Code Description MCC ID = 1
0929 MCC29 is too large.
if:
then:
MCC27 and MCC28 MCC29 must be within MCC27 + MCC29 < MCC28 – MCC29
are both non-zero
MCC27 is zero and MCC29 must be within MCC23 + MCC29 < MCC28 – MCC29
MCC28 is non-zero
MCC27 is non-zero MCC29 must be within MCC27 + MCC29 < MCC24 – MCC29
and MCC28 is zero
0943 MCC43 is too large.
if:
then:
MCC41 and MCC42 MCC43 must be within MCC41 + MCC43 < MCC42 – MCC43
are both non-zero
MCC41 is zero and MCC43 must be within MCC37 + MCC43 < MCC42 – MCC43
MCC42 is non-zero
MCC41 is non-zero MCC43 must be within MCC41 + MCC43 < MCC38 – MCC43
and MCC42 is zero
ID = 2
JGC – Jog Configuration Block
Error Code Description JGC ID = 2
0209 JGC09 is out of range. Valid range is 00000
≤
JGC09
≤
09999
0210 JGC10 is out of range. Valid range is 00000
≤
JGC10
≤
09999
0211 JGC11 is out of range. Valid range is 00000
≤
JGC11
≤
09999
0212 JGC12 is out of range. Valid range is 00000
≤
JGC12
≤
09999
0213 JGC13 is out of range. Valid range is 00000
≤
JGC13
≤
09999
0214 JGC14 is out of range. Valid range is 00000
≤
JGC14
≤
09999
0215 JGC15 is out of range. Valid range is 00000
≤
JGC15
≤
09999
0216 JGC16 is out of range. Valid range is 00000
≤
JGC16
≤
09999
0217 JGC17 is out of range. Valid range is 00000
≤
JGC17
≤
09999
0218 JGC18 is out of range. Valid range is 00000
≤
JGC18
≤
09999
0219 JGC19 is out of range. Valid range is 00000
≤
JGC19
≤
09999
0220 JGC20 is out of range. Valid range is 00000
≤
JGC20
≤
09999
0221 JGC21 is out of range. Valid range is 00000
≤
JGC21
≤
09999
0222 JGC22 is out of range. Valid range is 00000
≤
JGC22
≤
09999
0223 JGC23 is out of range. Valid range is 00000
≤
JGC23
≤
09999
0224 JGC24 is out of range. Valid range is 00000
≤
JGC24
≤
09999
0225 JGC25 is out of range. Valid range is 00000
≤
JGC25
≤
09999
0226 JGC26 is out of range. Valid range is 00000
≤
JGC26
≤
09999
0227 JGC27 is out of range. Valid range is 00000
≤
JGC27
≤
09999
0228 JGC28 is out of range. Valid range is 00000
≤
JGC28
≤
09999
0229 JGC29 is out of range. Valid range is 00000
≤
JGC29
≤
09999
0230 JGC30 is out of range. Valid range is 00000
≤
JGC30
≤
09999
0231 JGC31 is out of range. Valid range is 00000
≤
JGC31
≤
09999
0232 JGC32 is out of range. Valid range is 00000
≤
JGC32
≤
09999
0233 JGC33 is out of range. Valid range is 00000
≤
JGC33
≤
09999
0234 JGC34 is out of range. Valid range is 00000
≤
JGC34
≤
09999
0235 JGC35 is out of range. Valid range is 00000
≤
JGC35
≤
09999
0236 JGC36 is out of range. Valid range is 00000
≤
JGC36
≤
09999
0237 JGC37 is out of range. Valid range is 00000
≤
JGC37
≤
09999
