3–4 Status Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
Notes: For [ ] engineering units, see page 2.
Word Description Bit
For Hold Phase
The module latches each bit when executing the subject profile segment in closed loop, and drives its algorithm CV to
minimum (0%) in an attempt to control the profile setpoint.
The module unlatches each bit when it completes execution of the subject profile segment in open loop, or in closed
loop without driving its algorithm CV to minimum (0%).
This bit-
latched ON: when algorithm CV
is minimum during:
B08 Hold Segment 1
B09 Hold Segment 2
B10 Hold Segment 3
B11 Hold Segment 4
B12 Hold Segment 5
B13-B15 RFU
Pack Profile Actuals
Word Description
HPS09 Actual Pack Segment 1 Cavity Pressure [04] Average cavity pressure during last Segment 1.
HPS10 Actual Pack Segment 1 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 1.
HPS11 Actual Pack End of Segment 1 Position [12] Ram (Screw) position at completion of last Segment 1.
HPS12 Actual Pack Segment 2 Cavity Pressure [04] Average cavity pressure during last Segment 2.
HPS13 Actual Pack Segment 2 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 2.
HPS14 Actual Pack End of Segment 2 Position [12] Ram (Screw) position at completion of last Segment 2.
HPS15 Actual Pack Segment 3 Cavity Pressure [04] Average cavity pressure during last Segment 3.
HPS16 Actual Pack Segment 3 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 3.
HPS17 Actual Pack End of Segment 3 Position [12] Ram (Screw) position at completion of last Segment 3.
HPS18 Actual Pack Segment 4 Cavity Pressure [04] Average cavity pressure during last Segment 4.
HPS19 Actual Pack Segment 4 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 4.
HPS20 Actual Pack End of Segment 4 Position [12] Ram (Screw) position at completion of last Segment 4.
HPS21 Actual Pack Segment 5 Cavity Pressure [04] Average cavity pressure during last Segment 5.
HPS22 Actual Pack Segment 5 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 5.
HPS23 Actual Pack End of Segment 5 Position [12] Ram (Screw) position at completion of last Segment 5.
HPS24 - 25 RFU
Hold Profile Actuals
Word Description
HPS26 Actual Hold Segment 1 Cavity Pressure [04] Average cavity pressure during last Segment 1.
HPS27 Actual Hold Segment 1 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 1.
HPS28 Actual Hold End of Segment 1 Position [12] Ram (Screw) position at completion of last Segment 1.
HPS29 Actual Hold Segment 2 Cavity Pressure [04] Average cavity pressure during last Segment 2.
HPS30 Actual Hold Segment 2 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 2.
HPS31 Actual Hold End of Segment 2 Position [12] Ram (Screw) position at completion of last Segment 2.
HPS32 Actual Hold Segment 3 Cavity Pressure [04] Average cavity pressure during last Segment 3.
HPS33 Actual Hold Segment 3 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 3.
HPS34 Actual Hold End of Segment 3 Position [12] Ram (Screw) position at completion of last Segment 3.
HPS35 Actual Hold Segment 4 Cavity Pressure [04] Average cavity pressure during last Segment 4.
HPS36 Actual Hold Segment 4 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 4
HPS37 Actual Hold End of Segment 4 Position [12] Ram (Screw) position at completion of last Segment 4.
HPS38 Actual Hold Segment 5 Cavity Pressure [04] Average cavity pressure during last Segment 5.
HPS39 Actual Hold Segment 5 Ram (Screw) Pressure [01] Average ram (screw) pressure during last Segment 5.
HPS40 Actual Hold End of Segment 5 Position [12] Ram (Screw) position at completion of last Segment 5
HPS41 - 50 RFU
