4–18 Programming Error Codes
Publication 1771-6.5.126 – March 1998
Error Code Description HPC ID = 12
0231 HPC31 is out of range. Valid range is 00000
≤
HPC31
≤
09999
0234 HPC34 is out of range. Valid range is 00000
≤
HPC34
≤
09999
0237 HPC37 is out of range. Valid range is 00000
≤
HPC37
≤
09999
0240 HPC40 is out of range. Valid range is 00000
≤
HPC40
≤
09999
0261 HPC61 is out of range. Valid range is 00000
≤
HPC61
≤
09999
0409 HPC09 is out of range.
If non-zero, HPC09 must be within PKC45
≤
HPC09
≤
PKC46
0410 HPC10 is out of range.
If non-zero, HPC10 must be within PKC41
≤
HPC10
≤
PKC42
0412 HPC12 is out of range.
If non-zero, HPC12 must be within PKC45
≤
HPC12
≤
PKC46
0413 HPC13 is out of range.
If non-zero, HPC13 must be within PKC41
≤
HPC13
≤
PKC42
0415 HPC15 is out of range.
If non-zero, HPC15 must be within PKC45
≤
HPC15
≤
PKC46
0416 HPC16 is out of range.
If non-zero, HPC16 must be within PKC41
≤
HPC16
≤
PKC42
0418 HPC18 is out of range.
If non-zero, HPC18 must be within PKC45
≤
HPC18
≤
PKC46
0419 HPC19 is out of range.
If non-zero, HPC19 must be within PKC41
≤
HPC19
≤
PKC42
0421 HPC21 is out of range.
If non-zero, HPC21 must be within PKC45
≤
HPC21
≤
PKC46
0422 HPC22 is out of range.
If non-zero, HPC22 must be within PKC41
≤
HPC22
≤
PKC42
0424 HPC24 is out of range. Valid range is 00000
≤
HPC24
≤
PKC46
0425 HPC25 is out of range. Valid range is 00000
≤
HPC25
≤
PKC42
0426 HPC26 is out of range.
If non-zero, HPC26 must be within HDC45
≤
HPC26
≤
HDC46
0427 HPC27 is out of range.
If non-zero, HPC27 must be within HDC41
≤
HPC27
≤
HDC42
0429 HPC29 is out of range.
If non-zero, HPC29 must be within HDC45
≤
HPC29
≤
HDC46
0430 HPC30 is out of range.
If non-zero, HPC30 must be within HDC41
≤
HPC30
≤
HDC42
0432 HPC32 is out of range.
If non-zero, HPC32 must be within HDC45
≤
HPC32
≤
HDC46
0433 HPC33 is out of range.
If non-zero, HPC33 must be within HDC41
≤
HPC33
≤
HDC42
0435 HPC35 is out of range.
If non-zero, HPC35 must be within HDC45
≤
HPC35
≤
HDC46
0436 HPC36 is out of range.
If non-zero, HPC36 must be within HDC41
≤
HPC36
≤
HDC42
0438 HPC38 is out of range.
If non-zero, HPC38 must be within HDC45
≤
HPC38
≤
HDC46
0439 HPC39 is out of range.
If non-zero, HPC39 must be within HDC41
≤
HPC39
≤
HDC42
0441 HPC41 is out of range. Valid range is 00000
≤
HPC41
≤
HDC46
0442 HPC42 is out of range. Valid range is 00000
≤
HPC42
≤
HDC42
0503 You have selected CavPress/Time execution for the Pack Profile by HPC03-B00 = 1; how-
ever, your bit pattern in MCC02 indicates that your QI module is not configured for connec-
tion of a cavity pressure sensor.
