3–16 Status Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
Notes: For [ ] engineering units, see page 2.
Word Bit Description
SYS05 B03 = 0 Normal
= 1 High Screw RPM
The module sets this bit when real-time screw RPM equals or exceeds MCC55.
B04 = 0 Normal
= 1 High Cavity Pressure
The module sets this bit when real-time cavity pressure equals or exceeds MCC61.
B05-B07 RFU
B08 = 0 Normal
= 1 High Screw Rotate Jog RPM
Module sets this bit when responding to command DYC01-B09 = 1 and real-time screw RPM equals or exceeds JGC05
B09 = 0 Normal
= 1 High Ram (Screw) Jog Pressure
The module sets this bit when responding to command DYC01-B10 = 1 or DYC01-B11 = 1 and real-time ram (screw)
pressure equals or exceeds JGC06.
B10-15 RFU
SYS06 High Pressure Alarm Status (Real Time)
The module sets alarm bits on a real-time basis. These bits are not latched.
You can inhibit each bit by setting its associated alarm setpoint to zero.
B00 = 0 Normal
= 1 Injection Profile High Ram (Screw) Pressure
The module sets this bit when real-time ram (screw) pressure equals or exceeds INC57.
B01 = 0 Normal
= 1 Injection Profile High Cavity Pressure
The module sets this bit when real-time cavity pressure equals or exceeds INC58.
B02 = 0 Normal
= 1 Pack Profile High Ram (Screw) Pressure
The module sets this bit when real-time ram (screw) pressure equals or exceeds PKC57.
B03 = 0 Normal
= 1 Pack Profile High Cavity Pressure
The module sets this bit when real-time cavity pressure equals or exceeds PKC58.
B04 = 0 Normal
= 1 Hold Profile High Ram (Screw) Pressure
The module sets this bit when real-time ram (screw) pressure equals or exceeds HDC57.
B05 = 0 Normal
= 1 Hold Profile High Cavity Pressure
The module sets this bit when real-time cavity pressure equals or exceeds HDC58.
B06 = 0 Normal
= 1 Pre-decompress Movement High Ram (Screw) Pressure
The module sets this bit when real-time ram (screw) pressure equals or exceeds PRC57.
B07 = 0 Normal
= 1 Plastication Profile High Ram (Screw) Pressure
The module sets this bit when real-time ram (screw) pressure equals or exceeds PLC57.
B08 = 0 Normal
= 1 Post-decompress Movement High Ram (Screw) Pressure
The module sets this bit when real-time ram (screw) pressure equals or exceeds PSC57.
B09-15 RFU
SYS07 Overtravel Alarm Status (Real Time)
The module sets alarm bits in real time. These bits are not latched.
You can inhibit each bit by setting its associated alarm setpoint to zero.
B00 = 0 Normal
= 1 Ram (Screw) Overtravel at Bottom
The module sets this bit when real-time ram (screw) position is less than or equal to MCC13. The module resets this
bit when real-time position equals or exceeds the position defined by MCC13 + MCC15.
When SET, the module ignores any profile action execution command in DYC02.
