4–22 Programming Error Codes
Publication 1771-6.5.126 – March 1998
Error Code Description PLC ID = 14
0230 PLC30 is out of range. Valid range is 00000
≤
PLC30
≤
09999
0231 PLC31 is out of range. Valid range is 00000
≤
PLC31
≤
09999
0232 PLC32 is out of range. Valid range is 00000
≤
PLC32
≤
09999
0233 PLC33 is out of range. Valid range is 00000
≤
PLC33
≤
09999
0234 PLC34 is out of range. Valid range is 00000
≤
PLC34
≤
09999
0235 PLC35 is out of range. Valid range is 00000
≤
PLC35
≤
09999
0236 PLC36 is out of range. Valid range is 00000
≤
PLC36
≤
09999
0237 PLC37 is out of range. Valid range is 00000
≤
PLC37
≤
09999
0238 PLC38 is out of range. Valid range is 00000
≤
PLC38
≤
09999
0239 PLC39 is out of range. Valid range is 00000
≤
PLC39
≤
09999
0240 PLC40 is out of range. Valid range is 00000
≤
PLC40
≤
09999
0243 PLC43 is out of range. Valid range is 00000
≤
PLC43
≤
09999
0244 PLC44 is out of range. Valid range is 00000
≤
PLC44
≤
09999
0247 PLC47 is out of range. Valid range is 00000
≤
PLC47
≤
09999
0248 PLC48 is out of range. Valid range is 00000
≤
PLC48
≤
09999
0249 PLC49 is out of range. Valid range is 00000
≤
PLC49
≤
09999
0250 PLC50 is out of range. Valid range is 00000
≤
PLC50
≤
09999
0251 PLC51 is out of range. Valid range is 00000
≤
PLC51
≤
09999
0252 PLC52 is out of range. Valid range is 00000
≤
PLC52
≤
09999
0253 PLC53 is out of range. Valid range is 00000
≤
PLC53
≤
09999
0254 PLC54 is out of range. Valid range is 00000
≤
PLC54
≤
09999
0343 PLC43 is equal to PLC44. They must not be equal.
0347 PLC47 is equal to PLC48. They must not be equal.
0441 PLC41 is out of range. Valid range is 00000
≤
PLC41 < PLC42
0442 PLC42 is out of range. Valid range is PLC41 < PLC42
≤
09999
0445 PLC45 is out of range. Valid range is 00000
≤
PLC45 < INC46
0446 PLC46 is out of range. Valid range is PLC45 < PLC46
≤
09999
0457 PLC57 is out of range.
If non-zero, PLC57 must be within MCC17 < PLC57
≤
MCC18
0502 Your bit pattern in PLC02-B02, -B01, and -B00 indicates a selected screw RPM control
valve that is unconnected according to your entries in MCC02 and MCC04.
0506 Your bit pattern in PLC02-B06, -B05, and -B04 indicates a selected ram (screw) backpres-
sure control valve that is unconnected according to your entries in MCC02 and MCC04.
ID = 15
PPC – Plastication Profile Block
Error Code Description PPC ID = 15
0209 PPC09 is out of range. Valid range is 00000
≤
PPC09
≤
09999
0212 PPC12 is out of range. Valid range is 00000
≤
PPC12
≤
09999
0213 PPC13 is out of range. Valid range is 00000
≤
PPC13
≤
09999
0216 PPC16 is out of range. Valid range is 00000
≤
PPC16
≤
09999
0217 PPC17 is out of range. Valid range is 00000
≤
PPC17
≤
09999
0220 PPC20 is out of range. Valid range is PPC20
≤
PPC20
≤
09999
0221 PPC21 is out of range. Valid range is PPC20
≤
PPC21
≤
09999
0224 PPC24 is out of range. Valid range is 00000
≤
PPC24
≤
09999
0225 PPC25 is out of range. Valid range is 00000
≤
PPC25
≤
09999
0228 PPC28 is out of range. Valid range is 00000
≤
PPC28
≤
09999
