3–14

Status Word/Bit Descriptions

Publication 1771-6.5.126 – March 1998

Notes: For [ ] engineering units, see page 2.

Word

Description

RLS37

Plastication Segment 8

RLS38

Plastication Segment 9

RLS39

Plastication Segment 10

RLS40

Plastication Segment 11

RLS41 - 64

RFU

Bit-mapped Status Words

Word

Bit

Description

SYS01

B00-B07

Block ID = 00000001

Y

1

B08-B15

Power-up Status

B08

= 0 The module Wants Complete Download
= 1 Valid MCC on Board

Jog Execution Status

B09

= 0 Normal
= 1 Executing Screw Rotate Jog
The module sets this bit when responding to command bit DYC01-B09 = 1 and sets its outputs to JGC09–12.

B10

= 0 Normal
= 1 Executing Ram (Screw) Jog Forward
The module sets this bit when responding to command bit DYC01-B10 = 1 and sets its outputs to JGC17–20

B11

= 0 Normal
= 1 Executing Ram (Screw) Jog Reverse
The module sets this bit when responding to command bit DYC01-B11 = 1 and sets its outputs to JGC25–28

B12-15

RFU

SYS02

Profile Execution Status
The module sets each bit, SYS02 - B00 through B14 when:

S it completes the profile or movement, or

S it receives a new action execution command that terminates the profile or movement
The module resets each bit, SYS02 - B00 through B14 when:

S it starts the profile or movement, or

S it receives a valid DYC with DYC03-B10 SET

B00-03

RFU

B04

SYS02.B04 for QI(A) SYSB02.B04 for QI(B)
= 0 Normal
= 1 Injection Profile Complete
Important: The QI module will not set this bit during suspended injection.

B05

= 0 Normal
= 1 Pack Profile Complete

B06

= 0 Normal
= 1 Hold Profile Complete

B07

= 0 Normal
= 1 Pre-decompression Movement Complete

B08

= 0 Normal
= 1 Plastication Profile Complete

B09

= 0 Normal
= 1 Post-decompression Movement Complete

B10-14

RFU

Module Busy Status

B15

= 0 Normal
= 1 No Action in Progress
The module resets this bit when it is performing one of the following:

S executing a profile or decompression movement

S holding its outputs at any End of phase values

S executing any jog movement

SYS – System Status Block
