3–24 Status Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
Notes: For [ ] engineering units, see page 2.
Word Description Bit
B06 = 0 Normal
= 1 End of Hold Profile Set-Output in Progress
The module sets this bit when holding its outputs to HDC33-36 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B07 = 0 Normal
= 1 End of Pre-decompression Movement Set-Output in Progress
The module sets this bit when holding its outputs to PRC33-36 after completion of the movement.
The module resets this bit when it receives any new action execution command bit.
B08 = 0 Normal
= 1 End of Plastication Profile Set-Output in Progress
The module sets this bit when holding its outputs to PLC33-36 after completion of the profile.
The module resets this bit when it receives any new action execution command bit.
B09 = 0 Normal
= 1 End of Post-decompression Movement Set-Output in Progress
The module sets this bit when holding its outputs in PSC33-36 after completion of the movement.
The module resets this bit when it receives any new action execution command bit.
B10-15 RFU
SYS23 Double command error. You can determine from DYC01 which bits were set or downloaded at the same time.
SYS24 Double command error. You can determine from DYC02 which bits were set or downloaded at the same time.
Input Level In Engineering Units
The module reports real-time input levels scaled to engineering units.
Word Description
SYS25 Input #1 [11]
SYS26 Input #2 [01]
SYS27 Input #3 [25]
SYS28 Input #4 [04] or [25]
SYS29-32 RFU
Input Level, Raw Signal
Module reports real-time signals at the input to each A/D input converter.
Word Description
SYS33 Input #1 [24]
SYS34 Input #2 [24]
SYS35 Input #3 [24]
SYS36 Input #4 [24]
SYS37-40 RFU
Output Level in Percentage
Module reports real-time %-output it sends to each D/A output converter.
Word Description
SYS41 Output #1 [19]
SYS42 Output #2 [19]
SYS43 Output #3 [19]
SYS44 Output #4 [19]
SYS45-48 RFU
